Demonstration: OA-10/ voltage travel time mounted model control modelSupply voltage: K: 220VAC, F: 380VAC,Travel time: Sees the tableMounted model: Z: Direct-mounted, H: foot-plate,Control model: L: Two types, switch, switch quantity input, abbreviation: Integral-model and proportional modulating type,4---20mA inputS: Separated-model and proportional modulating type, 4---20mA inputY: Remote-control type, the switch quantity inputMain Technical parameters:The following parameters mainly apply to proportional modulating type; the 1, 2, 3, 4, 5, 6 rules are not suitable for remote controlled type and on-off type.1. Input signal: 4~20mA(or1-5V) DC2. Input channel resistance:250Ω3. Input channel number:1( separated model 3)4. basic error: 1%; 2.5%5. Return error: 1.5%6. Dead band: 0.5-3% continual and adjustable7. Damping characteristic: no swing8. Voltage of power supply:110V-460V9. Operating environment:Temperature:Integral model: -25~+75°CSeparated model: -25~+80°Cposition-localizer:-20~+75°CHumidity: ≤85% no corrosive characteristic exist in the ambient air.10. Protection class: in accordance with IEC14 IP65 (rainproof and dustproof); position-localizer GAMX in accordance with IEC14 IP44.
