thermal conductive insulator -INS1000
Posting date : May 25, 2018
Membership
Free Member Scince Jan 24, 2018
FOB Price
1
Min. Order Quantity
1
Supply Abillity
subject to demand
Port
TBD
Payment Terms
TBD
Package
TBD
Keyword :
Category
Contact
Zhou
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
Shanghai Xi Yue
HS-CODE
8514-40
Package & Delivery Lead Time
Package
TBD
Detailed Description
XiYue Industry T-INS 1000 is a mid-thermal performance thermal conductive insulating material which has wide range applications.
T-INS 1000 material thickness can be customized with the range from 0.25mm to 1mm which was benefited from XiYue Industry’s particular technology.
T-INS 1000 can be available with sheets or rolls package.
There are two different types material for T-INS 1000 to better meet customer’s special application. T-INS 1000(FG) which has fiber glass in formulation is more suitable for high shear and high torque requirements application case; T-INS 1000(F0) does not have fiber glass in formulation and it is more suitable for high thermal requirement application case.

Typical Applications:
-Power supplies 
-Semiconductors 
-Automotive 
-Telecom 
-Industrial

Material Features :
1. Mid-thermal performance for wide range application;
2. Excellent surface wetting performance to minimize material’s contact thermal
resistance;
3. Suitable surface tacky performance to better for customer’s application;
4. Customized material thickness to better fit customer’s application.
