DLXNY-FN02 wind and solar power generation training system consists of a photovoltaic powersystem, solar power systems, wind power equipment, wind power system, inverter and loadsystem, monitoring system components. DLXNY-FN02 wind and solar power generation systemusing training modules type structure, the devices and systems with separate functions, can becombined into photovoltaic training systems, wind power training systems
Technical parameter
1. Input voltage: AC220V ± 10% / 50Hz
2. Power consumption: wind simulation: 0.75KW simulated solar light: 200W
3. The system output power: 220VAC 1500W 12VDC 500W
4. The wind turbine: 12V / 300W
5. Start wind speed: 2.0 m
6. Wind wheel diameter: 1.3 m
7. The axial fan: 220V / 0.75KW 0-1440r / min
8. Solar Panel: monocrystalline 17.5VDC 10WPPolycrystalline 17.5VDC 30WP
9. Working environment: 0 ~ 40 ℃ ℃
10. Relative humidity: ≤85% RH
