China Flanged Top Entry Ball Valves
Posting date : Oct 18, 2016
Membership
Free Member Scince Oct 18, 2016
FOB Price
349
Min. Order Quantity
30
Supply Abillity
100000
Port
Shanghai
Payment Terms
L/C,T/T,D/A,D/P
Package
International standard packaging
Keyword :
Category
Contact
Jeasin Lee
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
Yaao
Model Number
YV-BAV-04
HS-CODE
8540-89
Package & Delivery Lead Time
Package
International standard packaging
Delivery Lead Time
15
Detailed Description
Flanged Top Entry Ball Valve
Design Specifications:
Size: From NPS 1/2 to NPS 4.
CLASS: From ASME 150 to ASME 2500LB.
Design: API 6D, API 608, ASME B16.34, DIN 3357.
Wall Thickness: ASME B16.34.
Pressure-temperature Rating: ASME B16.34.
Face-to-face Dimensions for Flanged Valves: ASME B16.10-API 6D.
Flange Design: ASME B16.5.
Socket Weld Ends to ASME B16.11.
Screwed Ends (NPT) to ASME B1.20.1- ASME B16.11.
Butt Welding Ends: ASME B16.25
Pressure Testing: API 598

Body Material:
A105, A182 F304, A182 F304L, A182 F316, A182 F316L, A352 LF2, A352 F11, A352 F22, A352 F5, A352 F51, A352 F321.

Quality Assurance (QA):
Every step from procurement through production, welding, assembly, testing, and packaging is in accordance with quality programs and procedures (ASME Section III manual and ISO 9001 manual).

China Valves Company : China Yaao Forged Valve Co., Ltd
Sales Contacts: Jeasin Lee
Sales e-mail: sales@yaaovalve.com
