Hanger Shot Blasting Machine for Auto Parts
Posting date : Oct 31, 2018
Membership
Free Member Scince Dec 09, 2015
FOB Price
200000 CNY
Min. Order Quantity
10
Supply Abillity
50000
Port
Xiamen
Payment Terms
LC,TT
Package
board
Keyword :
Category
Contact
Jeawin
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
Jingxing
Model Number
JX-HBM-04
HS-CODE
-
Package & Delivery Lead Time
Package
board
Detailed Description

Key Specifications / Features

The Hanger Shot Blasting Machine for Auto Parts is used in the surface treatment of small, medium or large auto Parts. It is made for increasing roughness of surface and shot peening to raise fatigue strength.
Main Technical Parameter:
Size of Blasting Jobs:Max. Size for work piece (diameter*height) Ф1100×1200mm. Blast nozzles(2 set) diameter of impeller: ф250 mm.Rotating speed: 2900r/min.Max.volume for blasting: 2×180kg/min.Power: 2×11kw. Lifting Hook:(double) Max. hangering weight: 1000kg.Speed of autorotation: 2.8m/min.Self-Rotating power: 0.55kw.Running speed: 20m/min.Walking power: 0.2kw.lifting speed: 8m/min.Lifting power: 1.5kw. Pulse Jet Type 1 set:Dust Collector Model SXLT-9.Cartridge Filter: Φ325 × 660 mm.Cartridge Filter Quantity: 9pcs. Air Volume: 9500m3/hr.Centrifugal Air Fan: 7.5kw.
Machine Details:Hanger Shot Blasting Machine for Auto PartsHanger Shot Blast Machine for Auto PartsHanger Shot Blasting Machine for Auto Parts-After Blasting
These Type of Machines Consist of Under Mentioned Parts:
1. Main Blast Cabinet with inspection Door2. Blast Wheel Units with Drive Mechanism.3. Abrasive circulation unit4. Bucket Elevator unit5. Abrasive Separation/Cleaning system with Storage Hopper6. Dust Collector with Cleaning Mechanism.7. Roller Conveyor system at Inlet & Outlet Side.8. Control Panel with PLC Control System.
JX Abrasives Standard Direct Drive Blast Wheel With High Performance
JX Shot Blasting Machine offers upgraded transport technology, high-efficient blast wheels and multiple machine sizes and types adhere to the customer’s shot-blasting needs.
