HDPE Plastic-Steel Large Diameter Hollow Wall Winding Pipe Extrusion Line

본문 바로가기


Home > Product > HDPE Plastic-Steel Large Diameter Hollow Wall Winding Pipe Extrusion Line
Product
HDPE Plastic-Steel Large Diameter Hollow Wall Winding Pipe Extrusion L...
Posting date : Jul 03, 2014
Membership
Free Member Scince Jul 02, 2014
FOB Price
120000-180000
Min. Order Quantity
1 Set
Supply Abillity
40 set/month
Port
Qingdao
Payment Terms
T/T L/C Western union
Package
Packing film and wooden cases in standard container or according to customers' requirements.
Keyword :
Category
Contact
Darcy
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
Longchangjie
HS-CODE
8477-20
Package & Delivery Lead Time
Package
Packing film and wooden cases in standard container or according to customers' requirements.
Delivery Lead Time
Within 30 working days.
Specifications
Type of Certification
CE/ISO9001
Start Date (validity period)
0000-00-00
End Date (validity period)
0000-00-00

Detailed Description
The extrusion line is mainly for producing large diameter hollow wall winding pipe ,Large diameter inding pipe (inner diameter from 50mm-2200mm) has high ring stiffness and high brunt intensity with structure It can be used for approxmate 50 years and hasmany advantages such as low cost assembly and easy operation ,ithstanding pressure corrosion resistant such as acid alkali and salt etc ,It is becoming as replacement of cement pipe and cast iron pipe nowdays Its beling widely used as sewerage and drinage pipe .
Production Line Features:
Model
KFYPG-800
KFYPG-1200
KFYPG-1600
KFYPG-2200
KFYPG-3000
Extruder Type
KFYSJ-65*30
KFYSJ-50*30
KFYSJ-65*33
KFYSJ-50*30
KFYSJ-80*33
KFYSJ-50*30
KFYSJ-90*33
KFYSJ-65*33
KFYSJ-100*33
KFYSJ-65*33
Output(kg/h)
250
120
300
120
500
150
750
250
900
300
Pipe specification(mm)
200-800
400-1200
800-1600
1200-2200
2000-3000
Production Speed(m/h)
2-16
2-12
1-6
0.5-5
0.3-3
Installed Power(kw)
180
250
300
400
500
The extrusion line is designed with adventaged technologedHigh speed and excellent extrusion quality by adopting two sets of single screw extruder with high efficiency prformance Unique design of composite diedead for large diameter winding pipe processing with poducessing with high production effeciency ,High quality of winding pipe produced by adopting the unique winding process Easy operation and high performance by adopting an andvanced PLC
1.resistance pressure,good impact.inside of pipe u type steel belt can substantially improve the pipe ring stiffness.
2.good nconomy .light weight transport,installation easy ,the price is cheaper.
3.resistance PH,Aging,not corrosion by sewage and chemistry,black pipe UV,extended uselife.
4.drainage ,sewage clear,inside of pipe small resistance,ablity to pass water strong,flow big.
5.connection safe reliable,can use the electric hot-melt,shrinnk belt,inside and outside welding and so on combination,connect firm,the pipe no leakage.
