CW5200 Water cooled chiller for electric spindle

본문 바로가기


Home > Product > CW5200 Water cooled chiller for electric spindle
Product
CW5200 Water cooled chiller for electric spindle
Posting date : Oct 13, 2015
Membership
Free Member Scince Apr 17, 2014
FOB Price
583 USD
Min. Order Quantity
1set
Supply Abillity
1000sets
Port
Guangzhou
Payment Terms
L/C, T/T, Paypal, Westem Union
Package
The chiller is packed in standard export carton.
Keyword :
Category
Contact
Mia
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
S&A
Model Number
CW-5200
HS-CODE
8415-81
Package & Delivery Lead Time
Package
The chiller is packed in standard export carton.
Specifications
Type of Certification
CE
Reference no.
CGZ3111012-00842
Name.
S&A
Start Date (validity period)
2011-10-17
End Date (validity period)
0000-00-00

Detailed Description
CW5200 Water cooled chiller for electric spindle S&A CW-5200 is refrigeration type water cooled chiller of 1400W cooling capacity. It is applied for cooling engrave electric spindle. It’s mainly used to have the heat generated during the laser device working that gone through the refrigerating cycle in compressor refrigeration system and eventually transferred to the air. Water cooled Chiller Specfications: One-stop automatic intelligent temperature control: in different environment, user does not need to change setting due to it will automatically switch to appropriate operating temperature. CW-5200AG: applied to cool a single 130W CO2 laser tube CW-5200AH: applied to a cool a single 8KW CNC spindle, welding equipment or two 100W CO2 laser tubes. CW-5200AI: applied to a cool single 50W-75W laser diode, a single15W-30W solid-state laser or a single 30W RF laser tube; Optional: CW-5202 dual water inlet and outlet series; heat booster; water filter. Voltage:110V-220V; Frequency: 50/60Hz; Refrigerant: R-22 / R-134a / R-410a Pump power: 0.03KW/0.05KW/0.1KW; Tank capacity:6L Max. lift:10M-25M; Max. flow: 10L/min- 16L/min N.W: 26Kgs; G.W: 29Kgs; Dimension : 58 X 29 X 47 cm (L X W X H); Packing dimension: 70 X 43 X 58 cm (L X W X H) About S&A Brand TEYU produces more than 60000 units of industrial chillers by year,we always insist on”Quality First” in design and production. “S&A” and “TEYU” have been enjoying high reputation among hundreds of manufacturers which are from both at home and abroad,and export rate reaches above 60% CONTACT S&A MSN: teyuchiller@hotmail.com TE:+86-20-89301885 FAX:+86-20-84309967 SKYPE: teyuchiller Email:marketing@teyuchiller.com Website: http://www.teyuchiller.com
