Hydraulic swing beam steel cutting machine
0 likes
China [CN] 1. The frame of hydraulic swing beam steel cutting machine is steel welded structure, have sufficient strength and rigidity, eliminate internal stress and high frequency vibration, to ensure the overall accuracy of the fuselage. Has a good rigidity, two cylinders fixed on the left and right columns (wallboard).
2.Hydraulic swing beam steel cutting machine adpots welded steel plate box-type structure, has a good rigidity, high-frequency vibration to eliminate internal stress, through the rear pivot point gap adjustment device for the center, and can quickly adjust the blade gap. Three-point support rolling clamping rail, and drive to make an up and down gate movement around the cylinder to complete shear.3 hydraulic Gate Structure, the return of the upper tool device, using accumulator type, speed of return. Three-point rolling bearing clamping rail, to maintain good accuracy, turret running smoothly, and can quickly adjust the blade gap.4 series fuel tank structure, synchronization performance, and the shear angle can be adjusted, cut high quality.5 The turret stroke can be adjusted in order to improve production efficiency.6. On the turret to introversion structure, easy to blanking, to improve the accuracy of the parts.7. Rectangular blade, four cutting edges, long service life.8. Jog, single inferior operating functions, commissioning, use, and easy maintenanceHydraulic system using integrated logic circuit, through the sequence valve control and smooth movement, low noise, simple to maintain.10 imported ring professionally produced fuel tank control the operation of the blade.11 pressing device when the sheet is not usual, can be free to expand pressed on the sheet. Binder fuel tank installed in front of the rack base plate, the overall circuit and stand-alone parallel compression cylinder. Into the oil pressure feed fuel tank, the head of the binder pressure to overcome the pressure of relay spring pressed sheet metal shear completed, by means of a relay spring relay reset.12 through potentiometer to control certain extent cut, shear adjustable stroke.13 The shear number of counter control.14 electrical control is centralized and reliable, as follows:Power facilities are located within the body, through the control panel button operation to control and achieve.Has a foot switch, through its direct clipping action, and convenient.Motor overload and short circuit protection, through the air switch.14 safe and reliable hydraulic system14 upper and lower knife using high quality materials, and all heat-treated, to ensure that it has sufficient hardness and long service life.
14 roller table, to facilitate feeding, and to ensure that the workspiece in the run-time is not scratched.
Each hydraulic swing beam steel cutting machine will be used steel rope to fix the four angles with the container, to avoid the machinery equipment move in the container.
Hydraulic swing beam steel cutting machine export standard wooden box package
