Piezo Drivers with Modularized drive power supply
Posting date : Dec 18, 2023
Membership
Free Member Scince Oct 17, 2016
FOB Price
according to the types
Min. Order Quantity
1
Supply Abillity
100
Port
Harbin
Payment Terms
T/T
Package
carton
Keyword :
Category
Contact
CoreMorrow
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
CoreMorrow
HS-CODE
8543-70
Package & Delivery Lead Time
Package
carton
Detailed Description

Parameters:



Type HVA-120.B1 Units
Functions Integrated power amplifier -
Channels 1 Channels
Control Open loop -
Control way  Analog/keyboard input, USB, spontaneous waveform -
Communication interface USB2.0, Compatible USB1.1
Analog input range Unipolarity 0~+10,bipolar -10~+10 V
Analog input impedance 100  KΩ±20%
Nominal voltage output Nominal 0~120(optional 0~150 ,200,300,±150) V
Porlarity Unipolarity/bipolar -
Output ripple 10 mV±20%
Output voltage resolution 16Bit 5mV(120V,150V,±150V),10 mV(200V,300V) -
Voltage stability <0.1 %F.S./8hours
Ave.output power 20 W±20%
Ave.output current 160 mA±20%
Peak output power 60 W±20%
Peak output current 500 mA±20%
Output proof Short-circuit proof, power limitation
Frequency response 5k Hz±20%
Dynamic power calculate PP voltage(V)×Frequency(Hz)×Load(F)≤Ave.output current(A)  (Ave.output power/nominal voltage output) -
External feature Membrane button, LCD display -
Software Standard configuration -
Spontaneous waveform function introduction Sine,square,triangle,saw wave -
LCD button communication interface Standard -
Input/output connection LEMO ERA.00.250.CTL -
Operating temperature range -10~+45
Environment humidity <85% -
Power supply AC 220V±10%  50Hz±10% -
Dimensions:L×W×H 380 × 280 × 170 mm
