Differential mode inductor cores
Posting date : Apr 26, 2016
Membership
Free Member Scince Mar 12, 2016
FOB Price
negotiable
Min. Order Quantity
100
Supply Abillity
100000
Port
Shanghai; Ningbo
Payment Terms
FOB
Package
customization
Keyword :
Category
Contact
Zhong
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
EHC
HS-CODE
8543-70
Package & Delivery Lead Time
Package
customization
Specifications
Type of Certification
ISO9001
Reference no.
00213Q13525ROS
Name.
ISO9001
Issued By
CQM
Start Date (validity period)
2013-06-21
End Date (validity period)
0000-00-00

Detailed Description
Output filter inductance is used to filter the AC ripple after rectification.If a larger direct current flow through the inductor, the magnetic permeability and inductance change the smaller the better under the condition of DC bias magnetic. That means within a certain range of DC magnetization ,the inductor has to have a constant magnetic conductivity characteristics ( or constant inductance characteristics).In other words, the magnetic permeability ( or inductance value) can’t be less than 50% of its initial value. Nowadays, amorphous magnetic cores have been widely used in output filter inductor.
Part No
Dimensions(mm)
OD
ID
HT
E101B03R01805
17.8
13
5
E101B03R01905
19
12
5
E101B03R02005
20
14
5
E101B03R01608
16
10
8
E101B03R01808
18
11
8
E101B03R02408
24
15
8
E101B03R01010
10
6
10
E101B03R01810
18
11
10
E101B03R02110
21
16
10
E101B03R02410
24
18
10
E101B03R02610
26
16
10
E101B03R03010
30
20
10
E101B03R04010
40
25
10
E101B03R05010
50
40
10
E101B03R05820
58
38
20
E101B03R07020
70
50
20
E101B03R10020
100
60
20
E101B03R12025
120
80
25
We can make customized dimension and specification.
