HCN brand 0205 series vibratory road roller of skid steer attachments

본문 바로가기


Home > Product > HCN brand 0205 series vibratory road roller of skid steer attachments
Product
HCN brand 0205 series vibratory road roller of skid steer attachments
Posting date : Apr 07, 2016
Membership
Free Member Scince Apr 05, 2016
FOB Price
US $2,000 - 15,000 / Set
Min. Order Quantity
1 set
Supply Abillity
200 Set/Sets per Year
Port
any Chinese port
Payment Terms
L/C T/T
Package
with the standard iron frame pacakge by LCL or FCL
Keyword :
Category
Contact
Lucy
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
HCN
Model Number
0205
HS-CODE
8432-80
Package & Delivery Lead Time
Package
with the standard iron frame pacakge by LCL or FCL
Delivery Lead Time
15 days after receiving the order and prepayment
Specifications
Start Date (validity period)
0000-00-00
End Date (validity period)
0000-00-00

Detailed Description

loader mounted vibratory roller

1.Product Descriptions:

1.Vibratory Roller for mini skid loader,vibratory roller for skid steer loader,vibratory roller

2.vibratory roller blade not directly contact with the ground,won't produce any damage to the road

3.The hydraulic drives of the vibratory roller are protected and isolated to provide maximum performance and reliability.
4.These hard-hitting units can deliver up to 3500kgs of dynamic force when operating at 95LPM.
5.It’s versatility makes the roller highly effective on a wide range of materials including sand, gravel, soils and asphalt.


2.Applications:



vibratory roller is used to vibrate the Rental fleets, contractors, landscaping, roadways, walkways, bike paths, golf courses, bridges and parking lots.





3.Technical Specifications:

vibratory roller model 020536 020548 020560 020566 020572 020584
drum width(mm) 914 1220 1614 1677 1855 2134
overall width (mm) 1067 1550 1720 1830 2007 2286
overall height (mm) 565 565 565 788 788 788
overall length (mm) 864 864 864 990 990 990
drum dimeter(mm) 530 530 530 609 609 609
operating weight(kg) 381 763 890 976 1044 1149
dynamic force(kn) 20 26 31 35 39 43
vibrating speed(vpm) 2600 2600 2600 2600 2600 2600
drum oscillation(degrees) 15 15 15 15 15 15
