30 channel telephone optical multiplexer
Posting date : Dec 07, 2015
Membership
Free Member Scince Dec 07, 2015
FOB Price
600usd/pair
Min. Order Quantity
1pair
Supply Abillity
1000pcs/week
Port
ningbo,shanghai
Payment Terms
T/T
Package
standard export carton package
Keyword :
Category
Contact
Soda
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
FCTEL
Model Number
FC-OV30
HS-CODE
8517-62
Package & Delivery Lead Time
Package
standard export carton package
Delivery Lead Time
3days
Specifications
Type of Certification
ISO9000
Start Date (validity period)
0000-00-00
End Date (validity period)
0000-00-00

Detailed Description
30PCM MUX Telephone fiber optical multiplexer

FC-OV30 provides 30Channel telephone 1-4Channel E1 interface, 4Channel 10M/100M Ethernet interface (Line Speed 100M) and 4 expansion interface. 4Channel Ethernet interface is switch interface, can support VLAN. 4 expansion interface can be used as the transmission channel of RS232/RS485/RS422 asynchronous data, voice signal, 2/4 line E&M audio signal, switch signal, Ethernet signal (Bandwidth 2M). It is very flexible.

Feature
  • Based on self -copyright  IC
  • E1 interface comply with G.703, adopts digital clock recovery and smooth phase-lock technology
  • Voice port supports FXO and FXS port, EM2/4 audio interface, FXO port docking with program-controlled switchboard, FXS port connected to the user's telephone;
  • Voice FXO/FXS access, supports caller ID feature and reverse polarity billing functions
  • Support various sites mutual number allocation function
  • Provide 4 expansion interface, you can extend 1~4Channel asynchronous data, such as    RS232/RS485/RS422/Manchester code; 1~4Channel voice, 1~8Channel switch , or two/four line audio and  so on
  • Ethernet interface supports10M/100M, half/full duplex auto- adaptable, support VLAN
  • 4Channel Ethernet interface is switch interface, support VLAN, can set to 4 channel logical isolation
  • Ethernet interface can support AUTO-MDIX (crossed line and straightly connected line self-adaptable )
  • The transmission distance is up to 2-120Km without interruption
  • AC 220V, DC-48V, DC24V can be optional
Technical parameters

Fiber
 Multi-mode Fiber
50/125um, 62.5/125um,
Maximum transmission distance: 2KM@62.5/125um  single mode fiber, attenuation (3dbm/km)
Wave Length: 820nm
Transmitting power: -12dBm (Min) ~-9dBm (Max)
Receiver sensitivity: -28dBm (Min)
Link budget: 16dBm
Single-mode Fiber
8/125um, 9/125um
Maximum transmission distance: 120Km
Transmission distance:120KM@9/125um  single mode fiber, attenuation (0.35dbm/km)
Wave Length: 1310nm
Transmitting power: -9dBm (Min) ~-8dBm (Max)
Receiver sensitivity: -27dBm (Min)
Link budget: 18dBm

FXS Phone Interface
Ring voltage: 75V
Ring frequency: 25HZ
Two-line Impedance: 600 Ohm (pick up)
Return loss: 40 dB

FXO Switch Interface
Ring detect voltage: 35V
Ring detection frequency: 17HZ-60HZ
Two-line Impedance: 600 Ohm (pick up)
Return loss: 40 dB

EM 2/4 Line
AD: 0dB
DA: -3.5dB
Two/Four-line Impedance: 600 Ohm
Return loss: 20 dB

Dimension
Product size:    19 inch 1U  483X138X44mm(WXDXH)
Simple packaging:  522X198X82mm(WXDXH)
Piece weight: 2.1KG

Power
Power supply: AC180V ~ 260V;DC –48V;DC +24V
Power consumption: ≤3W

Working environment
Working temperature: -10°C ~ 50°C
Working Humidity:        5%~95 % (no condensation)
Storage temperature:   -40°C ~ 80°C
Storage Humidity:         5%~95 % (no condensation

Network application
PBX-----30FXO--------(fiber optical cable)------30FXS------30*telephone
