automatic nc servo feeder for press
0 likes
China [CN] |
Features
|
|
Save space and increase efficiency.
|
|
Easy to install and operate.
|
|
It can be customized.
|
|
Suit for wide and long material.
|
|
Standard accessories
|
|
electric eye control system
|
|
outgoing catenary to assist and support the material
|
|
hold down arms device
|
|
advanced worm and worm gear adjustment
|
|
hand wheel adjuster
|
|
inverse curve roll
|
|
threading tables device
|
|
reference indicator adjuster
|
|
uncoiler contains the butterfly brakes air compressor
|
|
uncoiler-inverter device
|
|
rolls are hard chrome plated
|
|
coil tip flatness device
|
|
Optional accessories
|
|
Die-high electric conditioning
|
|
Hydraulic Material Feed-In Cart
|
|
Model
|
NCSF2-400
|
NCSF2-500
|
NCSF2-600
|
NCSF2-800
|
MCSF2-1000
|
|
Material Thickness
|
1.0-6.0mm
|
1.0-6.0mm
|
1.0-6.0mm
|
1.0-6.0mm
|
1.0-6.0mm
|
|
Material Width
|
70-400mm
|
70-500mm
|
70-600mm
|
70-800mm
|
70-1000mm
|
|
Feeding rolls
|
2
|
2
|
2
|
2
|
2
|
|
Straightening rolls
|
Up4/down3
|
Up4 /down3
|
Up4/down3
|
Up4 /down3
|
Up4/down3
|
|
Feeding speed
|
16m/min
|
16m/min
|
16m/min
|
16m/min
|
16m/min
|
|
Coil weight
|
5T
|
5T
|
5T
|
7T
|
8T
|
|
Coil I.D.
|
450-530mm
|
450-530mm
|
450-530mm
|
450-530mm
|
450-530mm
|
|
Coil O.D.
|
1600mm
|
1600mm
|
1600mm
|
1600mm
|
1600mm
|
|
Servo Motor
|
AC4.4kw
|
AC4.4kw
|
AC5.5kw
|
AC7.5kw
|
AC7.5kw
|
|
Uncoiler Motor
|
AC3.7kw
|
AC3.7kw
|
AC3.7kw
|
AC3.7kw
|
AC3.7kw
|
|
Uncoiler Expanding
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
|
Air power
|
5 kg/cm2
|
5 kg/cm2
|
5 kg/cm2
|
5 kg/cm2
|
5 kg/cm2
|
|
Feeding height
|
Customer request ± 100 mm
|
||||
|
Model/Coil Width/Coil Thickness
|
1.0
|
1.3
|
1.6
|
2.0
|
2.3
|
2.5
|
3.2
|
4.0
|
4.5
|
5.0
|
6.0
|
|
NCSF2-400
|
400
|
350
|
300
|
||||||||
|
NCSF2-500
|
500
|
400
|
350
|
300
|
|||||||
|
NCSF2-600
|
600
|
500
|
400
|
350
|
300
|
||||||
|
NCSF2-700
|
700
|
600
|
500
|
400
|
350
|
300
|
|||||
|
NCSF2-800
|
800
|
700
|
600
|
500
|
400
|
350
|
300
|
||||
|
NCSF2-1000
|
1000
|
800
|
700
|
600
|
500
|
400
|
350
|
300
|
|||
