Industry mineral dry powder briquette machine
0 likes
China [CN] Specification:
Production Capacity: 4-70t/h
Motor power: 5.5-130(kw)
Roller breadth:250-650 (mm)
Roller diameter :360-1250(mm)
Introduction:
1.Dry powder Briquette Machineis able to make full use of the raw material, and used to process sawdust, sugar cane, rice straw, rice stalk, corn stalk, cotton stalk, bean husk, into half-charcoal stick.
2.Dry powder Briquette Machinecan be used to heat boiler, fireplace,etc for warim in house. The length of the finished product can be controlled and changed as you need. Applications of
Application :
Dry powder Briquette Machineis widely used in the field of metallurgy, chemical, refractories etc, for reducing bug dust, controlling volume, recycling, easy transportation and storage. It has the properties of high efficiency, energy saving and environment protection
Benefits:
1.Dry powder Briquette Machineuses four bearings instead of three ones of old-type movement to add its stability and durability.
2.Dry powder Briquette Machineuse oil immersed type lubrication instead of old oiled lubrication. It could be used for many years as long as it isn't lack of oil.
3.Dry powder Briquette Machineincreases its screwptich to add input quantity in order to improve the capacity substantially.
4.Dry powder Briquette Machineimproves the shape of molding tube to reduce the frication between machine and raw materials and increase the density of briquettes.
Advantages:
1.Dry powder Briquette Machinekeeps water from flowing away and retains the nutrition in the straw.
2. Be convenient for stocking. High density, compact pellet mill and low moisture content make it easy to be stocked safely and chronically.
3. Easy to realize mechanized production.
4.No dust when burning and high hearing value
| Performance | FTM-360 | FTM-400 | FTM-500 | FTM-650 | |
| Output | hour (t/h) | 4 | 8 | 11 | 18 |
| Annual output (million t/y) | 1 | 2 | 3 | 5 | |
| Roller breadth (mm) | 250 | 280 | 300 | 336 | |
| Roller diameter (mm) | 360 | 400 | 500 | 650 | |
| Power(kw) | 7.5 | 11-15 | 18.5-22 | 20-30 | |
| Speed of mainshaft (r/min) | 18 | 15 | 13 | 13 | |
| Reducer | ZQ350 | ZQ400 | ZQ500 | ZQ650 | |
| ZQ400 | ZQ500 | ZQ650 | ZQ750 | ||
| Pressure form | Oblique iron constant pressure | Oblique iron constant pressure | Oblique iron constant pressure | Oblique iron constant pressure | |
| Axle bed pull rod | Axle bed pull rod | Hydraulic type | Hydraulic type | ||
| Interchangeable of hydraulic and constant pressure | Interchangeable of hydraulic and constant pressure | ||||
| Roller texture | 65Mn | 65Mn | 65Mn | 65Mn | |
| 9cr2Mn | 9cr2Mn | ||||
| Alloy steel | Alloy steel | Alloy steel | Alloy steel | ||
| Structural style | Double-roller&single pressure type | Double-roller&single pressure type | Double-roller&single pressure type | Double-roller&single pressure type | |
| Four-roller&dual pressure type | Four-roller&dual pressure type | Four-roller&dual pressure type | Four-roller&dual pressure type | ||
| Mainshaft bearing | 319×4 | 319×4 | 2097724×4 | 2097724×4 | |
| Principal axis | φ95mm | φ110mm | φ135mm | φ165mm | |
| 45# steel | 45# steel | Forge piece | Forge piece | ||
| Spherical size | User defined | User defined | User defined | User defined | |
