Specification :
Max.feeding size :60-285(mm)Processing capacity :80-725(m3/h)Weight:17000-38800(kg)Adjusting range of discharge opening:8-50(mm)Overview:1.High performance mini mine cone crusher is a advanced cone crusher that absorbs the advanced and developed crusher technology from all over the world. 2.This machine can process the ore and rock with the medium or above hardness, such as granite, basalt and limestone. It is widely used in the industry of metallurgy, construction, water conservancy, transportation, building materials.
Features:
1.Adapt to a wide range of high hardness materials and wide width feed size.
2.Reasonable structure, advanced crushing principle and technical parameters, make the operation stable and low cost.
3.With larger crushing force, make the production efficiency higher.
4.Various crushing chambers can adapt to a wide range of product size requirements.
5.Use hydraulic adjustment and hydraulic clear cone crusher chamber design, improve the degree of automation greatly.
6.The hydraulic system is convennient and reliable, can provide a effective protection of over load.
Advantages:
1.Less consumption of wearing parts, low operating cost
2.Laminating crushing, better shape of finished product
3.Hydraulic protection, hydraulic cavity clearing and high degree of automation, reducing downtime time
4, Thin oil for lubrication, reliable and advanced, improving the service life
5, A variety of crushing cavities, flexible, strong adaptability
6, Easy maintenance, easy operation
7.Hydraulic cone crusher is the latest generation of cone crusher which can replace spring cone crusher and update general hydraulic cone crusher in today’s mining industry, and it is ideal crushing equipment for large stone plant and mining crushing.
Technical parameters:
Model | Diameter of crushing cone(mm) | Max.feeding size(mm) | Width of discharge opening(mm) | Processing capacity(t/h) | Motor power(kw) | Swing frequency of main shaft | Total weight(t) | Dimensions(L×W×H)(mm) | |
PYB | 600 | 600 | 65 | 12-25 | 40 | 30 | 356 | 5 | 2234×1370×1675 |
PYD | 35 | 3-13 | 12-23 | 5.5 | 2234×1370×1675 | ||||
PYB | 900 | 900 | 115 | 15-50 | 50-90 | 55 | 333 | 11.2 | 2692×1640×2350 |
PYZ | 60 | 5-20 | 20-65 | 11.2 | 2692×1640×2350 | ||||
PYD | 50 | 3-13 | 15-50 | 11.3 | 2692×1640×2350 | ||||
PYB | 1200 | 1200 | 145 | 20-50 | 110-168 | 110 | 300 | 24.7 | 2790×1878×2844 |
PYZ | 100 | 8-25 | 42-135 | 25 | 2790×1878×2844 | ||||
PYD | 50 | 3-15 | 18-105 | 25.3 | 2790×1878×2844 | ||||
PYB | 1750 | 1750 | 215 | 25-50 | 280-480 | 160 | 245 | 50.3 | 3910×2894×3809 |
PYZ | 185 | 10-30 | 115-320 | 50.3 | 3910×2894×3809 | ||||
PYD | 85 | 5-13 | 75-230 | 50.2 | 3910×2894×3809 | ||||
PYB | 2200 | 2200 | 300 | 30-60 | 59-1000 | 280-260 | 220 | 80 | 4622×3302×4470 |
PYZ | 230 | 10-30 | 200-580 | 80 | 4622×3302×4470 | ||||
PYD | 100 | 5-15 | 120-340 | 81.4 | 4622×3302×4470 |
