China manufacturer YHZS35 mobile concrete batch plant

Product

Posting date : Sep 16, 2014

Click enlarge Image

Membership

Free Member Scince Sep 16, 2014

FOB Price

50000

Min. Order Quantity

Supply Abillity

100

Port

qingdao

Payment Terms

T/T Western union moneygram L/C

Package

standard packing

Keyword :

YHZS35 mobile concre

Category

Contact

lily zhao

0 likes

Product Detail

Company Info

Quick Detail

Place of Origin

China [CN]

Brand Name

haomei

Model Number

YHZS35

HS-CODE

Package & Delivery Lead Time

Package

standard packing

Delivery Lead Time

40days

Specifications

Start Date (validity period)

0000-00-00

End Date (validity period)

0000-00-00


Detailed Description

YHZS35 mobile concrete batch plant

1. Capacity as 35m3/h

2. Module structure, standard container and fast moving and so on

China manufacturer YHZS35 mobile concrete batch plant

YHZS35 mobile mix concrete plant is kind of Mobile Concrete Mixing Plant, based on the advantage of many models in China and overseas and the advanced technology, combing much experience in the past years. The batching unit, aggregate conveying unit, water supplying and additive agent supplying system, scaling system, mixing system, electrical control system and pneumatic system are centralized in one trailer zed chassis. It has the feature of instant trailing, instant stop, reasonable structure, well function, reliable working, convenient operation, accurate scale, particularly suitable for moving sites and construction site like road, bridge, dam, and airport.

The main features are as follows:

Adopting module structure, designed as per the loading of container standard. All modules are in one trailing unit. Installation and disassemble. Fast for moving. Main mixing unit is JS750 double-shaft, forced concrete mixer, with good mixing quality, high production efficiency. Perfect mixing can be done within ideal time period for dry-hard, half-dry-hard, plastic concrete with any mixing ratio. All scaling elements and control elements of scaling unit are imported elements and controlled by computer, guaranteeing completely accurate scale and stable function. Platform or ladder is equipped to each part need to maintenance and repair. Good for maintenance. The whole system adopts complete automatic system via computer, with dynamic panel display, to show clearly of the running of each part. Visualized monitor interface provides clear and accurate observing to the site working procedure. Table or list can be print out. Electrical control system adopts import elements, provided a stable and powerful function.

Technical parameters of mobile mixing concrete plant

Model		YHZS35
Output capacity		35m3/h
Mixing unit		JS750 concrete mixer
Max. aggregate size		60mm
Size of aggregate bin		45.5m3/211m3
Scale and conveying of aggregate		Scaled and lifted by belt conveyor
Scale of aggregate		2500kg±2%
Scale of cement		600kg±1%
Scale of water		300kg±1%
Scale of additive		20kg±1%
Power of whole unit		60 kw
Weight of whole unit		24T
Transport way		Semi-trailer
Discharge height		3.8m
Power		380v/50Hz
Total capacity		60Kw (excluding optional items)
Outline	In working	17.3mX3.4mX7.41m
	in transporting	17mX2.4mX4.34m
Trailer speed		≤40Km/h
Cement silo(option)		Depends on customer demand, 50T and 100T are available
Screw conveyor(option)		φ219 and φ273 are available

Pre-sale service

Suggest the best suitable products for customers according to their requirement, with sincere attitude

Try our best to Offer the technical service before installment.

Give our customers training for main problems and solution, maintenance and so on

During sale service

Supervising the whole process of producing and shipment and making sure our product deliver with good condition in time.

Offer all the necessary technical data to customer.

After sale service

Offer installment, debugging, and repairing service after customer receiving our products.

Offer work-site training.

Solve the customer’s complain at first time and try to arrive at the work site once get your notice.

We record every sold product on installment, debugging, and repairing situation. And provide professional maintenance advice.

We will visit customer timely to learn customer’s advice and new demand

Haomei machinery equipment co.,Ltd is located in the famous machinery capital of Zhengzhou, China. We are professional machinery products manufacturer-featuring a wide range of quality concrete mixer, concrete batching plant, mobile concrete plant, concrete pump, truck pump with boom, truck mixer, etc. We adhere to the policy of "QUALITY FIRST AND INTEGRITY WINS" to cooperate with clients from all over the world. Our company covers over 100 acres with workshop area of more than 50,000 square meters has 5 branches.

1. Why dose the customs choose our HAOMEI concrete mixer?

Specialize on manufacturing only concrete mixer.

Commitment used to serve clients as their solution partner.

What's the quality of your concrete mixer?

Rest assured that our products have got ISO, CE certificated. We have the professional team for the products' study and development.

What’s more, JS500 concrete mixer is on sale with a competitive price and I believe you will not miss this chance. We sincerely hope we can establish business relationship between us and welcome you visit our factory.
