Concrete batching plant
1. Capacity as 25m3/h
2. a new type ready-mix batching equipment which is movable by trailing
YHZS25 concrete batching plant
YHZS25 Mobile Concrete Batching Plant is new type ready-mix batching equipment which is movable by trailing. It is uniquely and novelty designed with a simple and compact structure. One trailing unit assembles a whole working set of aggregating, weighing, conveying and mixing system, enabling it great overall mobility. By absorbing new technologies from overseas and domestic, the mobile concrete mixing plant has such characteristics as accurate weighing, homogeneous and efficient mixing, fast and clean delivery, convenient to move and operate, safe trailing, etc. It is the ideal choice for projects that require frequent movement from one construction site to another.
Technical parameters
|
Item
|
YHZS25(3.8m)
|
|
theoretical productivity
|
25m3/h
|
|
weighing scale
|
concrete
|
2000kg
|
|
|
cement
|
510kg
|
|
|
water
|
150kg
|
|
|
liquid addictive
|
15kg
|
|
overall power
|
about 60KW
(optional parts not included)
|
|
power source
|
380V/50HZ
|
|
discharging height
|
3.8m
|
|
overall weight
|
20t(optional parts not included)
|
|
trail speed
|
≤40km/h
|
|
specification
(LxWxH)
|
during work
|
17x3.6x8.2m
|
|
|
during transportation
|
17.6x2.4x4.35m
|
The main features are as follows:
Adopting module structure, designed as per the loading of container standard. All modules are in one trailing unit. Installation and disassemble. Fast for moving. Main mixing machine has double-shaft, forced concrete mixer, with good mixing quality, high production efficiency. Perfect mixing can be done within ideal time period for dry-hard, half-dry-hard, plastic concrete with any mixing ratio. All scaling elements and control elements of scaling unit are imported elements and controlled by computer, guaranteeing completely accurate scale and stable function. Platform or ladder is equipped to each part need to maintenance and repair. Good for maintenance. The whole system adopts complete automatic system via computer, with dynamic panel display, to show clearly of the running of each part. Visualized monitor interface provides clear and accurate observing to the site working procedure. Table or list can be print out. Electrical control system adopts import elements, provided a stable and powerful function.
Pre-sale service
Suggest the best suitable products for customers according to their requirement, with sincere attitude
Try our best to Offer the technical service before installment.
Give our customers training for main problems and solution, maintenance and so on
During sale service
Supervising the whole process of producing and shipment and making sure our product deliver with good condition in time.
Offer all the necessary technical data to customer.
After sale service
Offer installment, debugging, and repairing service after customer receiving our products.
Offer work-site training.
Solve the customer’s complain at first time and try to arrive at the work site once get your notice.
We record every sold product on installment, debugging, and repairing situation. And provide professional maintenance advice.
We will visit customer timely to learn customer’s advice and new demand
Haomei machinery equipment co.,Ltd is located in the famous machinery capital of Zhengzhou, China. We are professional machinery products manufacturer-featuring a wide range of quality concrete mixer, concrete batching plant, mobile concrete plant, concrete pump, truck pump with boom, truck mixer, etc. We adhere to the policy of "QUALITY FIRST AND INTEGRITY WINS" to cooperate with clients from all over the world. Our company covers over 100 acres with workshop area of more than 50,000 square meters has 5 branches.
1. Why dose the customs choose our HAOMEI concrete machine?
Commitment used to serve clients as their solution partner.
Rest assured that our products have got ISO, CE certificated. We have the professional team for the products' study and development.
What’s more, our products are on sale with a competitive price and I believe you will not miss this chance. We sincerely hope we can establish business relationship between us and welcome you visit our factory.
