Fote Brand Energy Saving Steel Grinding Rod Mill Machine

Introduction of Fote Brand Energy Saving Steel Grinding Rod Mill Machine

The rod mill produced by Fote Machinery has wide applications. Its performance has reached the international advanced level. At present, the rod mill is the most effective, practical and reliable crushing machine, which is one of the widest used sand making equipment in the sand and gravel industry and which is mainly used to the processing and crushing of feldspar, quartz, mineral ore and other raw materials.

Besides, the rod mill is also applicable to fine crushing and medium crushing of grinding materials, refractory materials, cement, steel grit, slag powder, copper ore , iron ore, gold ore, concrete aggregate , asphalt aggregate and other hard and brittle materials. Additionally, the rod mill has a special effect on the pebble making, which is a kind of high-efficient and energy-saving crushing and sand making equipment, and which can sand 50% energy compared with traditional sand maker.

Application of Fote Brand Energy Saving Steel Grinding Rod Mill Machine

1. Reselection or magnetic separation in tungsten tin ore or other rare metal ore. In case the over-crushing, rod mill is often selected.

2. When secondary section grinding process is adopted, if the first section grind from 20-6mnm to 3-1mm adopting rod mill as the first section grinding machine has larger capacity and higher efficiency.

3. Under certain circumstances, rod mill can replace short-head cone crusher to conduct fine crushing. When the materials is soft or not very hard (especially the viscous ore),use rod mill grind19-25mm to 6-10 mesh has simple configuration than short-head cone crusher and can save costs.

Installation Instruction of Fote Brand Energy Saving Steel Grinding Rod Mill Machine

1. The installation position of rod milling sand concerns much with crushing machine. With different broken sites there is different installation position for rod mill and usually the rod grinders are installed in the plant or outdoor worksite.

2. Before install the rod mill, according to packing list, check all parts for any damage during transport, spare parts are included.

3. Check if all parts connection are solid and reliable, carefully check that the impeller has something else .Check for proper motor wiring and if voltage is normal.

Characteristics of Fote Brand Energy Saving Steel Grinding Rod Mill Machine

Compared with traditional equipment, Fote rod grinder can save energy by more than 40%. Uniform product particle contains few large particles and slurries. In contrast with the product particle of ball mill, the product particle of open-circuit rod mill has nearly the same characteristic curve with the closed-circuit ball mill.

The functional of Fote Brand Energy Saving Steel Grinding Rod Mill Machine

Rod mill is widely used in metal and nonmetal mines and water conservation, grinding of various ores or rocks in building materials sector. The rod mill operates from the motor drives through reducer and peripheral gear deceleration transmission the cylinder to rotate. The cylinder body is fitted with suitable grinding media- steel bars. Under the action of centrifugal force and friction, grinding media are raised to a certain level and thrown off or vent fell down.

Advantages of Fote Brand Energy Saving Steel Grinding Rod Mill Machine

Rod mill has dry and wet two types to choose, user could choose depend on the fact. The company uses the advanced output controllable technology, with the face milling material set the suitable miller, change the traditional surface contact into line contact, make the output granularity evener, high product, widely used in chemical industry, metallurgy, glassed industry, and the high requirement of the evenness for milling after milling, sand making of building sand in recent years.

Working Principle of Fote Brand Energy Saving Steel Grinding Rod Mill Machine

The electro motor drives the cylinder to rotate through the reduction gears and the peripheral rack wheel reducer transmission, or the low speed synchronous motor directly drives the cylinder to rotate through the peripheral rack wheel reducer transmission. Inside the cylinder, there are proper ore grinding media-steel rod. Under the eccentric force and frictional force, the ore grinding media are lifted to a certain height and fall down in the state of dropping. The materials to be ground continuously go into the cylinder from the ore feeding mouth and are crushed by the moving grinding media, and then are discharged by the overflow and the force of continuous feeding to go to the next procedure.

Parameter

About us

Henan Fote Heavy Machinery Co., Ltd., the former Henan First Machinery Factory, founded in Henan Zhengzhou- China machinery manufacturing capital in 1982, is a large joint-stock company specialized in manufacturing heavy mining machinery and civilian machinery; it has six production bases with an area of 240,000㎡, more than 2000 existing employees, 160,000 ㎡ standardized heavy industrial plant, and about 500 sets of big and medium sized processing, riveting, welding and assembly equipment.

After 30-year construction and development, Fote has become famous production and export base of mining machinery and civilian machinery in China.

Making technical innovation as core strategy, Fote has established Beneficiation Machinery Research Institute, Crushing Machinery Research Institute, Powder-grinding Machine Research Institute and Building Materials Equipment Research Institute; as well, we have established good relationships with Harbin University, Tsinghua University, Zhejiang University and a number of well-known domestic universities to achieve resource sharing and complementary advantages, and speed up the transformation of scientific and technological achievements.

After long-term technology research and international exchange, qualities and technology contents of Fote products have achieved international top level and received wide recognition and praise in the international market; Fote products are exported to more than 90 countries and regions such as the United States, Russia, Kazakhstan, Turkey, Iran, South Africa, Ethiopia, Egypt, Viet Nam, Malaysia, India, Australia, Korea, Chile,etc.

Being customer-oriented, Fote is committed to providing the best solutions and turn-key projects for global customers; and relying on new advanced customer service platform, we provide customers with comprehensive, complete and 24-hour one-stop services.

Fote immutably ranks customers first and credit foremost. We are looking forward to achieving a win-win situation with you by first-class technology, first-class products and first-class service !

Our Services

Full service of Fote

1 .Pre-sale services: enthusiasm

We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.

2 .Sale services: servant

Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.

3 .After-sale services: faithfulness

To establish long term friendship, we will regularly pay return visit to customers.Supplying technique, building design, instruction, installation and debugging for free.

4 .We provide one-year warranty to make sure your machine runs consistently.

We always offering lifelong services and provide spare parts for a long term,and repair main parts under right using for free in two years.
