HY 9055 of Electronic Potting Silicone Rubber

본문 바로가기


Home > Product > HY 9055 of Electronic Potting Silicone Rubber
Product
HY 9055 of Electronic Potting Silicone Rubber
Posting date : Aug 10, 2014
Membership
Free Member Scince Aug 09, 2014
FOB Price
6usd/kg
Min. Order Quantity
200kg
Supply Abillity
8ton/day
Port
Shenzhen
Payment Terms
T/T,L/C,D/D,D/C
Package
25kg/drum,200kg/drum
Keyword :
Category
Contact
Tommy
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
Hong Ye
Model Number
9055,215,210
HS-CODE
3910-00
Package & Delivery Lead Time
Package
25kg/drum,200kg/drum
Delivery Lead Time
3days
Specifications
Start Date (validity period)
0000-00-00
End Date (validity period)
0000-00-00

Patent
Start Date
0000-00-00

Detailed Description

1. Product Feature of Electronic Potting Silicone RubberHY 9055 silicone rubber is a kind of low viscosity, Inherent flame resistance, two components addtion cured potting silicone with heat-conducting. It cures with both on room temperature and heated temperature. It has the feature of the higher temperature the faster of the curing time. It can be applied to electronic components for insulation, waterproofing, fixed and flame retardant. It mainly applied in electronic components surface with materials of  PC(Poly-carbonate)、PP、ABS、PVC, etc. and metal materials.
2. Typical Application of Electronic Potting Silicone Rubber
HY 9055 electronic potting silicone rubber could be applied to
- high powered electronics,
- DC/DC module and circuit board which requires heat dissipation and high temperature resistance.
-It can be broadly used for LED screen, Wind Power Generator, PCB substrate, etc.3. Technical Guidelines of of Electronic Potting Silicone Rubber
a, Pls put part A and part B in separate container and stir evenly before mixing the two part together.
b, Mixing Ratio: part A: part B = 1:1
c, Deaeration the mixture in vacuum pump under 0.08 MPa for 3-5 minutes.Then the mixture could be used for pouring.4.Notes of Electronic Potting Silicone Rubbera.The following material may hinder the curing of HY 9055, So pls use after the test. When necessary, pls clean the application areas.
Organotin compound or Condensation silicone with organotin
Sulphur, sulfide and sulfur rubber materials.
Amine compounds as well as contains the amine materials.
Pewters solder flux
b. HY 9055 should be sealed storage.The mixture should be used up disposably to avoid causing waste.
c. HY 9055 belongs to non-dangerous goods, but keep away from mouth and eyes.
d. When it gets stratified after a period of storage, Please mix it evenly before using,which does not affect the performance.
PACKAGE20Kg/pail as a set (Part A 10Kg + Part B 10Kg)


SHELF LIFE AND TRANSPORTATION
1. Twelve(12) months when stored at 24C in tightly closed original packages.
2. This kind of product is non-dangerous product, which could be transported as general chemicals.
3. Storage beyond the expired date doesnot necessarily mean that the product is no longer usable. In this case however, the properties required for the intended use must be checked for quality assurance reasons.

More information about transparent silicone rubber, pls contact Ms Tammy:
Tel: +86-0755-89948019
Mob: +86-18938867580
Mail:hyjm(at)szrl(dot)net
