TRX Series Coaxial Cable PTFE Insulation with 3 Shield for Aerospace Systems
0 likes
China [CN] The TRX Series Tri-Shield Coaxial Cables (including TRX-178, TRX-179, TRX-316, TRX-180, TRX-142, TRX-400) are premium-grade RF interconnect solutions engineered for critical applications requiring exceptional signal integrity. The triple-shielded design provides superior protection against electromagnetic interference (EMI), ensuring low noise and stable performance in demanding environments.
Structure:
· Inner Conductor: Silver-plated Copper Alloy
· Insulation: PTFE (Polytetrafluoroethylene)
· Inner Shield: Silver-plated Copper Braid
· Inner Jacket: FEP (Fluorinated Ethylene Propylene)
· Outer Shield: Silver-plated Copper Braid
· Outer Jacket: FEP (Fluorinated Ethylene Propylene)
· Precision PTFE Insulation: Delivers consistent electrical performance, low loss, and high-temperature resistance.
· High-Density Triple Shielding: Multi-layer braided shields achieve excellent shielding effectiveness, minimizing signal leakage and external interference.
· Low Noise & High Immunity: Advanced construction resists signal interference, reducing noise and ensuring clean signal transmission.
· Enhanced Signal Integrity: Optimized design improves data transmission accuracy and long-term stability.
| Model | Inner Conductor | Insulation (mm) | Inner Shield (mm) | Inner Jacket (mm) | Outer Shield (mm) | Outer Jacket (mm) |
|---|---|---|---|---|---|---|
| TRX-178 | 7/0.10 | 0.86 | 1.26 | 1.88 | 2.29 | 2.95 |
| TRX-179 | 7/0.10 | 1.60 | 2.00 | 2.51 | 2.92 | 3.58 |
| TRX-316 | 7/0.17 | 1.52 | 1.93 | 2.44 | 2.85 | 3.56 |
| TRX-180 | 7/0.102 | 2.59 | 3.00 | 3.51 | 3.91 | 4.57 |
| TRX-142 | 1/0.94 | 3.00 | 3.50 | 4.22 | 4.72 | 5.46 |
| TRX-400 | 19/0.203 | 3.00 | 3.45 | 4.22 | 4.72 | 5.46 |
Typical Applications
These high-performance tri-shield cables are ideal for:
· RF & Microwave Systems: Transmitters, receivers, and antenna feeds
· Test & Measurement: High-frequency test benches and signal analyzers
· Aerospace & Defense: Avionics, radar systems, and mili tary communications
· Telecommunications: Base stations, broadcast equipment, and high-speed data links
· Medical Equipment: MRI, RF surgical tools, and diagnostic instruments
