Electronic speed controller With 400A,12S LiPo Powerful Ever
0 likes
China [CN] Xiongcai Technology has been specializing in speed controller since 2011. With expertise, we make electronic speed controller for RC hobbies as excellent as top brands such as Castle Creation MAMBA XLX2, Spektrum Firma etc.
A powerful speed controller XC201-E3 comes with:
1. Current: Continuous current 400A, peak 800A
2. Output: 6-12s Li-Po
3. Motor: Sensored or sensorless brushless motor
4. Speed: <240,000RPM
5. BEC: 6.0V, 7.4V, 8.4V, continuous current 10A, peak 25A
6. Mobile App & Bluetooth: Parameter setting, firmware upgrade
7. Dimension: 127.5*81.0*59.5mm
In these years, we have earned ourselves
a place in the severe competition with top brands such as Castle and Hobbywing.
In 2024, we engineered a new power monster-E3. E3 is a powerful product which
is engineered for enthusiasts’ RC cars and trucks. Six months ago, a notable RC
car brand contacted us and consulted about technical problems. They wanted to
develop a most powerful electronic speed controller ever in RC car industry.
Comparing to existing products, E3 is really a power monster.
E3
is high performance with 400A continuous current, 6-12S Lipo, 16-54v power
system, as I know, maybe it’s the most powerful motor controller (electronic speed controller or ESC)
adopting to sensored or sensorless brushless motor, and supporting 240,000RPM
maximum. BEC power is optional (6.0V, 7.4V, 8.4V), providing 10A continuous
current, you can select it according the servo specification.
We
know that thermal management is important to a powerful electronic device. We
design the frame meticulously. With the combination of forged Al case and fin
fan, E3 allows max airflow throughout the part to cool critical component down,
promoting thermal performance to a new level. With epoxy potted,
waterproof design will protect electronics and promote heat dissipation in
all weather conditions.
Fan
is controlled intelligently by ESC. When the internal temperature of system
exceeds 55 Celsius Degree, the fan will be turned on, otherwise, the fan will
be turned off. If there is an abnormal heavy current, the ESC will cut off the
power to fan, and the ESC will work normally.
Many
parameters related to handling can be adjusted by mobile app via Bluetooth
communication, such as running mode, number of Li-Po cell, cutoff voltage,
throttle rate, braking force, turbo timing, initial PWM, etc. and firmware can
be managed on app as well.
Power
is one thing, the most important is how can we control it perfect to avoid
negative impact? We have designed many protection measures including low
voltage, throttle loss, abnormal braking, over temperature, short circuit to
fan, and so on. We need performance, also we need safety.
We
have been staying focused on design and manufacture of electronic speed
controller for 13 years, serving top clients in their industries. Parts are
certified by CSIPER25, ISO11452-2, ISO10605, ISO16750, ISO7637. We provide a
full service from design, analysis, testing to supply, you don’t need to worry
about the quality and reliability.
Have a try, contact us or google Shenzhen Xiongcai Technology for detail. If you have any special concept or requirement, we will help you achieve your ideas.
