Honzhan HZ-E324 A3 size Eco solvent flatbed printer 320×440mm
0 likes
China [CN] Honzhan HZ-E324 A3 size Eco solvent flatbed printer 320×440mm
1. Printer application:
Eco solvent flatbed printer can print on many flat surface materials, such as wood, acrylic, plastic, resin, foam board, KT board,
PVC, metal, aluminum, glass, ceramic, stone, sticker, leather, phone case, pens, crystal, ABS/EVA, golf ball, bottle, etc.
2. Printer features:
The advantages of our Honzhan HZ-E324 A3 size digital Eco solvent flatbed printer:
1). Our Eco solvent printer equipped with Epson XP600 printhead to meet the demand of high resolution and faster speed.
Epson XP600 printhead has 6 channels×180nozzles=total 1080 nozzles, its inkjet volume and speed are great.
2). Our printer using industrial grade control boards, realize industrial-grade product design,
belongs to industrial printing machine, fast printing speed, very less after-sales problem.
3). Eco solvent ink prints images has glossy and bright effect.
4). Automatic capping system is easy operation and maintenance for our printer.
5). We use specially R&D printing software for our printers, very stable and easy to operate, complete in operation data.
3. Technical parameters:
Model | HZ-E324 Eco solvent flatbed printer |
Printhead | 1pc Epson XP600 printhead, optional 2pcs printheads |
Nozzle type | Micro Piezo Inkjet Printing |
Print Resolution | 360*720dpi, 720*720dpi, 720*1440dpi, 1440*1440dpi, 720*2880dpi |
Printing size | 320×440mm |
Print materials thickness | 0-250mm |
Operation interface | Button operation panel |
Print mode | Unidirection or Bidirection |
Nozzle clean | Auto cleaning system with anti clogged flash spray and moisturizing function |
Material application type | Wood, acrylic, plastic, foam board, PVC, metal, aluminum, glass, ceramic, stone, sticker, leather, phone case, crystal, golf ball, bottle and many flat surface materials. |
Printing Speed | 3 square meters per hour |
Ink type | Eco solvent ink |
Ink color | CMYK or CMYK+LC+LM |
