GWTM-0418 Gear Head Automatic Taping Machine
0 likes
China [CN] SPECIFICATION:
Tape width | 15(20,25,30) | Max.winding speed | 120rpm |
Max.final coil.O.D | φ130—650 | Tape spacing | Proportional linkage |
Min.final coil.I.D | φ60 | Supply voltage | AC 220V（50Hz） |
Max.finalcoil height | 150 | Mechanical dimensions | 900×600×1800 |
Controller storage capacity Programs | 29 set | Weight | 240kg |
FEATURES：
Gear Head Automatic Taping Machine will place insulating tapes on cores and windings in closely controlled fashion.
Automatic Taping Machines are fast and will work with polyester,polyimide and Aramide tapes as well as copper shielding tapes in widths from 6 to 16mm or as specified.
Tape is loaded onto the magazine and cut automatically，and the winding speed increased in order to finish the job in minimum time.
The magazine of Automatic gear head taping machine may be exchanged in minutes to accommodate different tape widths.
ADVANTAGES:
High accuracy: stepper motor guarantees high accuracy
The cut surface is flat: the hot knife can heat seal the cut surface of the color ribbon and the light and thin textile belt, and the sealing is smooth and free of burrs.
The blade is made of imported high-quality steel and has a long service life.
Automatic operation: just set the length and number of cuts you need, and the rest of the work is done automatically.
Automatic pause: Once the material is used up, Gear Head Automatic Taping Machine will automatically stop working. Bouncer automatic alarm
Memory function: automatically store the cut length, cut quantity and cut speed before shutdown
APPLICATION:
Gear Head Automatic Taping Machine for application of insulation tape to wound coils. it is best suited to toroidal inductor, toroidal transformer, toroidal current transformer, toroidal coil, toroid choke coil, power inductors, power magnetics, UPS inductor, converter inductors, heavy toroidal core,etc.
The coil is placed by an operator on a rotating spindle, and the machine automatically applies the required number of turns of insulation tape, secures the end of the tape with a wiping action, and ejects the coil from the machine.
It's an accurately and reliability digital automatic toroid-taping machine. it is used for wraping the insulation tape on the toroidal core and windings. Automatic Toroid Transformer Coil Taping Machine is designed to operate with a wide variety of insulation tapes, including Kapton, Polyester, PEN, PVC, PPS, and most other woven and non-woven types.
PRACTICAL APPLICATION :
TRAINNING CUSTOMER TO OPERATE WINDING MACHNE :
1.All service engineers with 10 years experience are gotten special technology training, who can deal with various breakdown problem.
2.Guide the user to use accurately and how to maintain the Gear Head Automatic Taping Machine.
Provide free consultation about production process technology of electronic Gear Head Automatic Taping Machine.
3.In order to guarantee the machine used normally, we'd have training on how to operate, use and maintain our product by English manual, video, guiding on line.
PACKAGING:
Packaging Material: Carton/Wooden case with foam inside.
1.General package(Paper carton or plastic bag): For small euipped parts for Gear Head Automatic Taping Machine , Package it with form and pack paper to guarantee unbroken during the transport.
2.Wooden case package: For larger scale Gear Head Automatic Taping Machine we have special skilled carpenter, who would make the proper wooden case with exact thickness,density,length. The up arrow ↑marked on the outer wooden case. Buffer material would be put in the wooden case to prevent crack and shock.
