Poe5912 Poe separator Poe combiner standard IEEE802.3AF 15.4W
0 likes
China [CN] Two models: poe5912 and poe5912g
IEEE 802.3af compliant
Three adjustable voltage outputs of 5V / 9V / 12VDC are provided
The maximum transmission distance is 100 meters
100M Ethernet port
Plug and play, no management required
Poe5912 separator is an economical and practical Poe remote power receiving device with high performance and high reliability, which is based on IEEE 802.3af standard. It can separate the power transmitted through the network cable from the data signal. Poe 5912 can be used with power supply equipment conforming to IEEE 802.3af standard (such as pse908ex, pse1816g, pse802g, etc.), which can provide data and power supply for network equipment that does not support Poe at the same time. Poe5912 can output 5V / 2A; 9V/1.1A; 12V / 1A three voltages, used together with power supply equipment, can flexibly expand home network and office network without being limited by power line layout.
Click enlarge Image
