Dual-wall Semi Hard Heat Shrinkable End

The double wall semi-rigid heat shrinkable end is composed of semi-rigid polyolefin and hot melt adhesive. The outer layer is radiation crosslinked polyolefin and the inner layer is hot melt adhesive. One end of the product has been pre contracted and sealed, which has double effects of insulation and sealing. It is used for mechanical protection, sealing, waterproof and moisture-proof and environmental protection of power cables, wires and harness ends.

Product features

■ shrinkage temperature: ≥ 80 ℃

■ Final shrinkage temperature: ≥ 125 ℃

■ Service temperature - 45 ~ 110 ℃

■ Heat shrinkable ratio: 4:1

■ Standard color: Black

■ Voltage class: medium and low voltage power cable (35kV and below)

■ Purpose: radiation crosslinking heat shrinkable sealing cap is suitable for the end waterproof, insulation and protection treatment of power cable or communication cable. The mouth end is coated with high-performance hot-melt adhesive. When heated, the sealing cap can shrink, and the glue melts. It is tightly bonded to the surface of the cable, playing an excellent waterproof, insulation and protection effect.
