Embossing Unit 3000 Sheets / Min 380V 50HZ Napkin Folding Machine
0 likes
China [CN] Full Automatic Napkin Making Machine With Embossing And Lamination Unit
Description
Full Automatic Napkin Making Machine With Embossing And Lamination Unit is used for making napkin tissue by embossing, folding, electronic counting and cutting.The machine size varied from 200mm to 430mm to be customerized. The machine is customerized and additional function like color printing and lamination can be specified. The speed for the two deck napkin making machine is 3000 sheets / min for 200mm size and 2200 sheets / min for 300mm size.
Specification
Folding size | 140*140mm |
Unfolded size | 280*280 mm |
Specification of raw paper | <= 560*1200 mm |
Machine capcaity | speed is 1600 pcs/min |
Folding way | double triangle 1/4 folding |
Embossing unit | The buyers should prepare it by themselves,we provide drawing |
Paper breakdown device (it is set between embossing unit and forming unit .). | |
One group knives:it automatically cut raw paper. | |
The guide pipe is made from aluminum alloy,which can make sure the concentricity. | |
Feeding part:It adopts belt to control the feeding process ,AP ration geal can adjust stepless. | |
Loading material pneumatically(the buyer should prepare the air compressor by himself ). | |
Sharpen the knives pneumatically . | |
Automatic counting system, | |
Main motor is frequency conversion motor:3kw,380v,50HZ. | |
Machine head transmission | standard struction commutator. |
Output holder is double layer and made from stainless steel. | |
Spare Parts List
NO | ITEM | QUA |
1 | Plastic male knife | 4 |
2 | Band Saw | 2 |
3 | Tool Box | 1 |
4 | Grinding Stone | 4 |
Feature
Speed: 3000 sheets / min
Folding Type: 1 / 4 and 1 / 8 or 1 / 6 or M fold or Two folding Type
Embossing: steel to steel or steel to paper.
Important parts Bearing: NSK
Important parts Steel: SKD
PLC: Delta
Frequency Converter Delta
Pneumatic Parts AIRTACK
Motor: SIEMENS
Pneumatic Parts AIRTAC
Photoelectrical switch (magic eye) Omron
20mm thickness wall board plate for back stand
40mm thickness wall board plate for embossing unit and color printing unit
30 mm thickness wall board plate for cylinder folding parts
Introduction of main parts
Paper-feeding part
One Layer and Belt to deliver paper and controlled by Pump
Raw Paper Manual Adjustment
Embossing Part
One unit steel to woolen Roller
Mechanical pressure control
cotton cloth and paraffin oil Cleaning Device
Folding Part
Leading Paper Roll Function , the folding tension of the fore part adjustable
Counting Device: Pneumatic dislocation type
Control Unit
Frequency Conversion Device
Automatic Counting Function
Emergency Device
Voltage: AC380V 50HZ Main Motor 2.2KW,
Air pressure required less than 0.5 MPA
