Bldc Fan Motor Arc Segment MSDS Y33 Starter Motor Magnets
0 likes
China [CN]
Starter Motor Permanent Ferrite Magnet Arc-Segment
Application:
permanent magnet DC motor or customized Automobile Starter Accessories, starting motor accessories, magnetic tile.
1. Material:strong Y35 ferrite magnet
2. Grade: Y25, Y30, Y30BH, Y33,Y33BH,Y35
3. Shape: Arc, Block, Bar, Ring, Cube, Disc, or others.
Magnetization:
Anisotropic ferrite magnets are different, they are all oriented in the manufacturing direction, and should be magnetized in the direction of orientation.
Specification
| Gade | Br(mT) | Hcb(KA/m) | Hcj(KA/m) | (BH)max(KJ/m3) | ||||
| mT | Gs | KA/m | Oe | KA/m | Oe | KJ/m3 | MGOe | |
| HT-2 | 380-395 | 3800-3950 | 250-270 | 3140-3391 | 260-285 | 3265-3580 | 29.0-31.5 | 3.64-3.95 |
| HT-2A | 390-400 | 3900-4000 | 270-285 | 3391-3580 | 275-300 | 3454-3768 | 29.0-31.0 | 3.64-3.89 |
| HT-3 | 405-415 | 4050-4150 | 250-270 | 3140-3391 | 260-275 | 3265-3768 | 31.0-33.5 | 3.89-4.20 |
| HT-3A | 415-425 | 4150-4250 | 230-250 | 2889-3140 | 240-260 | 3014-3265 | 31.0-34.0 | 3.89-4.27 |
| HT-3B | 400-415 | 4000-4150 | 275-290 | 3454-3642 | 285-310 | 3580-3893 | 31.8-33.7 | 4.0-4.23 |
| HT-4 | 410-420 | 4100-4200 | 300-315 | 3768-3956 | 310-330 | 3893-4145 | 31.0-35.0 | 3.89-4.40 |
| HT-4A | 420-435 | 4200-4350 | 260-285 | 3265-3579 | 270-290 | 3391-3642 | 33.0-37.0 | 4.14-4.64 |
| HT-4B | 395-410 | 3950-4100 | 310-330 | 3893-4145 | 360-380 | 4521-4772 | 28.0-32.0 | 3.52-4.02 |
| HT-5 | 410-430 | 4100-4300 | 300-320 | 3768-4019 | 375-390 | 4710-4898 | 33.0-36.0 | 4.14-4.52 |
FAQ:
1.How about the quality of the magnets?
We have alibaba factory checking tesing report, ISO9001:2008 quality system certificated.
2.How long will you give me the reply?
We will contact you in 12 hours as soon as we can.
3.How is the price?
As we believe the quality is the most important,we will provide the best quality magnet we can with reasonable price.
4.Could you provide me the shortest lead time?
We have materials in our stock,if you really need,you can tell us and we will try our best to satisfy you.
5.If I have paid,when will you help me to produce?
When we have received the money in our account,we will give you the receipt and arrange to produce immediately.
