LED programmable three phase digital voltmeter ammeter combination electricity analyzer controller
0 likes
China [CN] | Parameter | |||
| Signal input | Wiring | Three-phase four-wire Y34/three-phase three-wire V33 | |
| Voltage | Range | 400V/100V LED three phase digital voltmeter ammeter combination | |
| Overload | Continuous: 1.2 times Instantaneous: 2 times | ||
| Power consumption | ＜1VA | ||
| Current | Range | 5A/1A three phase digital voltmeter analog output 4-20ma | |
| Overload | Continuous: 1.2 times Instantaneous: 2 times | ||
| Power consumption | ＜1VA | ||
| Frequency | 40-65Hz three phase digital ammeter digital input output | ||
| Power supply | AC220V (default) or AC/DC80-270V | ||
| Communication | RS485 communication interface, physical layer isolationMODBUS-RTU protocol in line with international standards Communication speed 1200-9600Calibration method N81, E81, 081 | ||
| Simulation output | 0/4-20mA or 0-5/10V transmitting output programmable settings, transmission items and corresponding values. low voltage switchgear use digital panel meter with RS485 | ||
| Relay output | Programmable remote control / Alarm relay outputCapacity 5A/250VAC 5A/30VDCProgrammable alarm, power, switch input, simulation input or remote control | ||
| Telemetry switch | Telemetry switch input measurement, passive dry node inputProgrammable switch alarm output CE approved panel mount programmable switchboard LCD digital power meter | ||
| Circumstance | Operating temperature：-10~55℃Storage temperature：-20~75℃ | ||
| Switch |
Insulation: signal, power supply, output terminal to shell resistance > 5MΩWithstand voltage, signal input, power supply, output >AC2KV
|
||
