DENSO 5SER09C for Toyota Yairs Auris auto ac air conditioning compressor

Our factory can produce many kinds of auto Air Conditioner Compressors with good quality and one year quality warrantee.

DENSO 5SER09C Toyota Yairs Auris ac compressor

Specification:

Model number: INTL-XZC1167

Type: DENSO 5SER09C

Pulley: 6PK

Volt: 12V

Clutch: 100mm

Number of channels: 6Diameter pulley: 100 mm.Compressor capacity: 90 cc.Oil capacity: 150 ml.Inlet diameter: 18.3 mm.Output diameter: 15.5 mm.Models: 1.3 VVTi - 1.4 D4D -

Special Notes:

OEM#

88310-0D210

883100D210

447150-0340

4471500340

DCP50248

DCP50305

Basic Requirements when servicing an A/C system:

1, The Accumulator or Filter Drier should always be replaced when the Air Conditioning System is opened. For warranty Purposes buyer must show evidence of receiver/drier replacement. In some vehicles the drier comes attached to the condenser so it must replaced as well

2. A/C system must be clean and free of debris and contaminants. In most cases components can be flushed; however in some instances it may be necessary to replace the condenser or other items.

3. Orifice tube must be replaced; expansion valve must be inspected and replaced if dirty or defective.

4. Correct amount and type of oil must be used. Please refer to the OE manufacturer for this information.

5. Prior to refrigerant charging, full vacuum must be done for a minimum of 45 minutes. In humid climates or during cooler days, this time should be increased to effectively remove air and boil off moisture.

6. The Orifice Tube, if equipped, should always be replaced and the Expansion Valve, if equipped, should at least be inspected for proper operation if not replaced
