China construction material machine floor deck roll former for sale

Product

Posting date : Oct 23, 2019

Click enlarge Image

Membership

Free Member Scince Oct 10, 2018

FOB Price

USD60000

Min. Order Quantity

1SET

Supply Abillity

100SET

Port

SHENZHEN

Payment Terms

By TT

Package

Container

Keyword :

floor deck machine

Category

MACHINERY & ELECTRICAL | Nuclear re | Metal-roll | Rolls for

Contact

Rebaca

0 likes

Product Detail

Company Info

Quick Detail

Place of Origin

China [CN]

Brand Name

Superda

Model Number

YX60-500

HS-CODE

8455-30

Package & Delivery Lead Time

Package

Container

Delivery Lead Time

60days

Specifications

Type of Certification

Reference no.

OP160755

Name.

METAL FORMING CE

Issued By

ITATLY

Start Date (validity period)

2016-10-11

End Date (validity period)

0000-00-00


Detailed Description

China construction material machine floor deck roll former for sale

YX60-500 Forming machine

一、Technical parameters

No.	ITEM		PARAMETER	REMARK
1	MATERIAL	Type	Cold-rolled strip steel, galvanized sheet
		T.(mm)	0.8-1.2mm
		Yield Strength (Mpa)	Q235
2	Forming product Width		150,200,250,300,350mm
3	Forming speed (m/min)		2-8m	Including hole
4	Forming main power (KW)		7.5 KW	FYR
5	Hydraulic power (KW)		18.5 KW	FYR
6	Bending power (KW)		3 KW	FYR
7	Voltage		AC380V，50Hz，3P

Metal forming process

(A) 2 in 1 Uncoiler Straightening→servo feeder→Hydraulic press breach device → Guide device → roll forming machine → hydraulic punch →shear device (including knife)→ finished product rack

Shenzhen Supera Machine Co., Ltd. specializes in the production of metal sheet metal forming machine.

Gearbox drive style Highway guardrail roll forming machine,completed process Uncoiler →Guide device→Straightening→Hydraulic press breach device → roll forming machine → hydraulic punch →shear device (including knife)→ finished product rack.Hydraulic station：30KW Hydraulic punch hole & shear use same station .

Using, Forming highway guard rail;

Place of Origin,China;

Business type,manufacturer;

lead time,60-90 days;

Machine color,customized;

Certification,CE report;

Condition,new;

HS Code,84552210;

Supply ability,15sets/Month;

Packaging,container;

After-saler service,engineer available to service machinery in oversea;

PLC,Panasonic;

Operation type,Touch screen;

Hydraulic system pressure,12MPa;

Hydraulic motor power,30kw;

Model: YX51-240-960

Floor deck roll forming machine for mass production construstion material foor deck.

Floor deck name as floor board, also known as profiled steel plate, steel plate, steel floor plate. It was first called the profiled steel plate, which is the collective name for all the steel plates pressed by the plate press.

The floor slab is made of galvanized steel sheet by roll forming, and its cross section is V-shaped, U-shaped, trapezoidal or similar. It is mainly used as a permanent template and can also be selected for other purposes.

The earliest profiled steel plates were mainly used for roof slabs on the factory floor, and later there were profiled steel plates for the floors, which were gradually classified as floor deck.
