Vitrified bond CBN Grinding Wheel is suitable for high-efficient heavy grinding of camshaft of automobile parts

Product

Vitrified bond CBN Grinding Wheel is suitable for high-efficient heavy...

Posting date : Oct 10, 2018

Click enlarge Image

Membership

Free Member Scince Jul 02, 2018

FOB Price

30 USD

Min. Order Quantity

1 slier

Supply Abillity

200 slier every week

Port

Shanghai

Payment Terms

T/T, Western Union, MoneyGram

Package

carton box with foam box (Gift package is available)

Keyword :

Introduction of vitrified bond diamond grinding wheels

Vitrified bond diamond grinding wheels possess pretty high abrasive resistance, especially in polishing hard and brittle workpiece. It has many advantages like small grinding force, low operating temperature, high grinding precision, excellent workpiece's surface grinding, etc. Therefore, vitrified bond diamond grinding wheel will express the better advantages in the future. It is recognized as a high performance grinding wheel with the higher speed, higher efficiency, higher precision, lower abrading cost and lower pollution. Based on these superiorities, vitrified bond diamond bruting wheel is widely used in wafer, PDC, PDC, diamond cutter, CBN, cemented carbide, new engineering structural ceramic, diamond, jewel, crystal, rare earth materials and another hard-brittle materials' machining operation.

Applications of vitrified diamond wheels for PCD and PCBN tools :

PCD cutting tools, PCBN cutting tools, CVD tools, MCD tools, milling cutter, reamer, drill and regrinding, etc

Vitrified bond CBN Grinding Wheel is suitable for high-efficient heavy grinding of camshaft of automobile parts.The wheel speed is 80m/s-160m/s,Designed to used on CNC Cam Grinders like Toyoda,Schaudt,Landis,Junker etc.

The Features Of Vitrified CBN Grinding Wheels For Camshaft

Sharp cutting, high efficiency, long life, less heat and jam generated in grinding, easy control of the precision and easy dressing.

The Specifications Of Vitrified CBN Grinding Wheel For Camshaft:

Model	D (mm)	T (mm)	H (mm)	X (mm)
1A1	150	6	32	3, 5
1A1	200	10	32	3, 5
1A1	250	10	75, 152.4	3, 5
1A1	300	12	127, 152.4	3, 5
1A1	350	15	25, 40, 100, 152.4	3, 5
1A1	400	14	100	3, 5, 8
1A1	450	15	100	3, 5, 8
According to customers requirements .
Model and Type	D (mm)	T (mm)	H (mm)	X (mm)
vitrified CBN 1A1	150	6	32	3

Product description of vitrified bond diamond grinding wheels

1.Vitrified bond diamond grinding wheel possess pretty high abrasive resistance, especially in polishing hard and brittle workpiece.

2.Vitrified bond diamond grinding wheel has many advantages like small grinding force, low operating temperature, high grinding precision, excellent workpiece's surface grinding, etc.

3. Vitrified bond diamond grinding wheel recognized as a high performance grinding wheel with the higher speed, higher efficiency, higher precision, lower abrading cost and lower pollution.

4.Vitrified bond diamond grinding wheel is widely used in wafer, PDC, PDC, diamond cutter, CBN, cemented carbide, new engineering structural ceramic, diamond, jewel, crystal, rare earth materials and another hard-brittle materials' machining operation.

Production process of ceramic diamond grinding wheel:

1. Mix: the binders and diamond powder are fully stirred and fused in a certain proportion

2. Weighing: weighing according to the volume, ring width and density of the grinding wheel required by the customer

3. Feeding: put mixed diamond powder and binding agent into the grinding tool

4: compression ring (let stand for a period of time to wait for molding)

5: back mould

6: the abrasive layer is air-dried

Cook for 10 hours at 7:670 degrees

8: cooling (prepare the matrix at the same time)

9. Fixed decoration of the whole

10: measure stationarity

Why choose our product

More SuperHard Products Co., Ltd is dedicated to finding solutions that help our clients in all markets succeed. More SuperHard has been manufacturing high-quality, competitively priced superabrasive diamond and cbn tools that are designed to perform in a wide range of industrial ,such as pcd tools grinding, natural diamond polishing, auto parts processing , thermal spray coated industry, optical glass, semicon and led industry, woodworking tool , cnc tool grinding and roll machining ,others ultral precision industry.

The company production and sales of products covered vitrified bond tools, resin bond tools, metal bond tools, electroplated diamond/cbn tools, vaccum brazed products, cvd diamond tools, polycrystalline diamond (pcd) tools, cubic boron nitride (cbn) tools.our objective is to meet all the customers’ needs and help every customer achieve maximum benefits. more brings in revenue for you, you win, we win!

More SuperHard supplies the wheels for several application mainly:

1.Carbide round tools on cnc machines : flute grinding, gash grinding, end facing, clearance angle and cylindrical grinding .

2. Insert grinding for machines such as: agathon, wendt, haas, waida and ewag.

3.Woodworking saw blade and tools .

4.Hss tools

5.Cutting wheels

Our product’s advantages:

1.High grinding efficiency

2.Wonderful edge quality

3.Long service life

4.High polishing efficiency

5.Large Exports

6.Considerable after-sell service

7.Amazing performance

8.Various types and sizes available

9.Direct Factory Manufacturer

10.Backing/substrate material: Aluminum

11.Abrasive layer: diamond

12.Bond: vitrified

13.Excellent cutting edges

14.Reduced cycle times

15.Custom Engineered

If you have any questions, please contact us

Whats App:+8618638297665

Skype:18638297665

Alisa@moresuperhard.com

Tel:18638297665

URL:www.moresuperhard.com

Product needed: Resin bond diamond grinding wheel

1) Diameter (25, 40,100,200,300…750mm)

2) Hole/state bore dimension

3) Thickness (4/5/6/8/10/…40/50/60mm)

4) Shape (1A1 /1A1R/1A8/1A1W/1L1/1F1/6A2/12A2/11V9/4A1/14A1…)

5) Grit size (16/18, 18/20…40/45,80/100…325/400. In GB or ISO standard)

6) Other request
