RYKM1200 High Speed Three Color Flexo Printing & Slotting and Online Folder Gluer and Strapping machine

본문 바로가기
Home > Product > RYKM1200 High Speed Three Color Flexo Printing & Slotting and Online Folder Gluer and Strapping machine
Product
RYKM1200 High Speed Three Color Flexo Printing & Slotting and Online F...
Posting date : Mar 19, 2018
Membership
Free Member Scince Mar 19, 2018
FOB Price
10,000-300,000 USD
Min. Order Quantity
1
Supply Abillity
2/30days
Port
Tianjin,Shanghai,Ningbo,etc
Payment Terms
L/C,TT
Package
Wooden Box or any metal container
Keyword :
Folder Gluer Machine
Category
MACHINERY & ELECTRICAL | Nuclear re | Printing m | Flexograph
Contact
Mike Chong
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
Royal
HS-CODE
8443-16
Package & Delivery Lead Time
Package
Wooden Box or any metal container
Delivery Lead Time
30days
Detailed Description
Machine introduction：
  1. This machine is component with the feeding unit,printing unit,slotting unit and rotary die-cutting unit,can accomplish the process of the corrugate paperboard printing,slotting and die-cutting.
  2. The materials of the body is HT250,thickness of body is 60mm,after second stage annealing ,making by CNC machine,with high strength and high precision.
  3. All the transmission gear is spiral gear,with low noise and high precision,gears after high frequency heating and grinding,adopt automatic circle lubrication.
  4. The gear material is 20CrMnti alloy steel,after high frequency heating and grinding.and the main transmission gear and roller adopt expansion sleeve connection.
  5. Bearing adopt the famous brand made in China like HRB and WANXIANG.
  6. The mail motor adopt frequency converters adjust,the frequency is “Delta” brand made in Taiwan,the PLC also adopt “Delta” brand made in Taiwan,the contactor adopt “Seimens” brand.
  7. The rubber roller adopt Jizhou Chunfeng Yinxing rubber roller, famous brand in China.
  8. Anilox roller adopt “Haili” brand, famous brand in China.                                             Mail technic parameter.
  9. Max.design machine speed: 250 sheets/min.
  10. Economy produce speed: 220 sheet/min.
  11. Max. paper coverage area: 1270×2400mm
  12. Min. paper coverage area:380(full block print)×650mm.
  13. Effective print area:1220×2200mm.
  14. Printing precision: ≤±0.5mm.
  15. Slotting and die-cutting precision: ≤±1.5mm.
  16. The standard thickness of the printing plate:7.2mm.
  17. Skip feeding size is 1450×2400mm.
  18. Max. slotting depth: 320mm
  19. Min. slot distance:280×80×280×80mm
  20.                 Or:160×160×160×160mm
  21. Body thickness 60mm
  22. Gear thickness: 50-70mm
  23. Invoter:Delta
  24. Touch screen and PLC:DELTA
  25. Contactor:Seimens
  26. Anilox roller:Haili
  27. Bearing:HRB and WANXIANG
  28. Rubber anvil:Osting Italy
