Product Name
|
Barcode scanner DE1200
|
Interface Type
|
11PIN Pitch 1.25
|
Communication Mode
|
USB(USB-KBW、USB-COM), TTL, RS232, PS2
|
Power Supply
|
DC 5V@100mA(work)
|
Light Source
|
Visible red light, 625±10nm
|
Scan Type
|
Linear CCD
|
CPU
|
32-bit
|
Resolution
|
2500
|
Scan Tolerance
|
300times/s
|
Depth of field
|
30mm-700mm
|
Scan Mode
|
Manual ,Continuous, Auto Sense, Flashing
|
Scan Angle
|
Roll±30°, Pitch±60°, Skew±60°(PCS90%, Code 39, 10mil/0.25mm)
|
Print Contrast Signal
|
≥20%
|
Ambient Light
|
Dark environment, indoor natural light
|
Symbologies
|
UPC-A,UPC-E,EAN-8,EAN-13,ISSN,ISBN,Code 128, GS1-128,ISBT 128, Code 39,Code 93,Code 11, Interleaved 2 of 5,Matrix 2 of 5,Industrial 2 of 5,Standard 2 of 5(IATA),Codabar(NW-7),Plessey,MSI Plessey,RSS,China Post,etc.
|
||
Environmental
|
|||
Operating temperature
|
-20℃ to 50℃
|
Storage temperature
|
-40℃ to 70℃
|
Humidity
|
5% to 95%(non-condensing)
|
Drop Height
|
1.2 m
|
Transport vibration Test
|
10H@125RPM
|
|
|
Depth of field
|
|||
5MIL
|
80-120mm (PCS90%,Code 39)
|
13MIL
|
30-320mm (PCS90%,Code 39)
|
20MIL
|
30-450mm (PCS90%,Code 39)
|
40MIL
|
130-700mm (PCS90%,Code 39)
|
Accessories List
|
|||
Cable(Optional)
|
USB Cable, used to connect the DE1200 to a host device.RS232 Cable, used to connect the DE1200 to a host device, with USB supply cable.PS2 Cable, used to connect the DE1200 to a host device and keyboard input device.
|
||
Power Adaptor
|
Output: DC5V 1A, input: AC100~240V 50~60Hz(serial port optional).
|
