150KW Diesel Generator Set with Volvo Engine
Posting date : Aug 13, 2017
Membership
Free Member Scince Aug 08, 2017
FOB Price
1
Min. Order Quantity
1 set
Supply Abillity
7000 sets/year
Port
Shanghai, Shenzhen
Payment Terms
T/T
Package
Wooden case
Keyword :
Category
Contact
Angela Ou
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
Shuang Tong
Model Number
XG-150GF
HS-CODE
8502-12
Package & Delivery Lead Time
Package
Wooden case
Delivery Lead Time
30 days
Detailed Description

Diesel Generator Set Data

Set Type: XG-150GF

Prime Power: 150KW/187.5KVA

Rated Current: 245(A)

Rated Frequency: 50(Hz)

Start-up time: 5~6(s)

Power Factor: 0.8(Lag)

Rated Voltage: 400/230(V)

Standard Features

1. Engine: VOLVO TAD732GE

2. Radiator 50℃ max

3. Fans are driven by belt, with safety guard

4. 24V charge alternator

5. Dry type air filter, fuel filter, oil filter

6. Alternator: single bearing alternator

7. IP23, insulation class H/H

8. Main line circuit breaker

9. Standard control panel

10. Absorber

11. Muffler

12. User manual

Diesel Engine Data
Manufacturer: VOLVO
Model: TAD732GE
Standby/Prime Power: 178KW/162KW
Rated Speed: 1500(r/min)
Cycle: 4 stroke
Cylinder Arrangement: 6 in line
Displacement: 7.15L
Bore and Stroke: 108*130(mm)
Compression Ratio: 18:1
Governor Type: Electronic
Start battery voltage: 24V DC

Air Intake System
Air Intake System: Turbo, Air/Air Cooling
Max Intake Restriction: 3.5kpa
Burning Capacity: 12.4m3/min
Air Flow: 222 m3/min

Exhaust System
Exhaust Gas Flow: 35.1 m3/min
Exhaust Temperature: 542℃
Max Back Pressure: 5kPa

Fuel System
Fuel System: Directly Injection Fuel System, Bosch Pump
100%( Prime Power) Load: 196g/kwh
50%( Prime Power) Load: 211g/kwh

Oil System
Total Oil Capacity: 29L
Oil Consumption: ≤0.08L/h
Engine Oil Tank Capacity: 31L
Oil Pressure at Rated RPM: 480kPa

Cooling System
Cooling Way: Water-cooled
Total Coolant Capacity: 37.1L
Thermostat: 87-102℃
Max Water Temperature: 105℃
