Engineering plastic high wear-resistance UHMWPE plastic sheets
0 likes
China [CN] Engineering plastic high wear-resistance UHMWPE plastic sheets
The Material Of UHMWPE
UHMWPE is the abbreviation of ultra high molecular weight polyethylene. This is the most excellent quality available for use in harsh working environments and in a variety of applications. Applicability is very good in many highly difficult applications.
UHMWPE is a product that have many advantages that not to many plastics and be used many fileds.
The Advantage Of UHMWPE
1. Wear-resistance
The wear resistance of UHMW-PE ranks first in plastic, and exceeds that of certain metals.
|
Material |
UHMW-pe |
MC nylon |
PA-66 |
PTFE |
POM |
HDPE |
PVC |
Carbon steel |
Brass |
|
Mortar wear index |
1 |
4 |
5 |
5 |
6 |
10 |
10 |
7 |
27 |
2. Impact resistance
The impact strength of UHMW-PE at the top of all engineering plastic.
|
Material |
UHMWPE |
PA 66 |
PC |
ABS |
PBT |
|
Unit(KJ/m2) |
140 |
9 |
80 |
15 |
5 |
3. Self-lubrication
UHMWPE has a very low coefficient of friction(0.05-0.11),so that it has a very good self-lubrication.
4. Corrosion resistance
UHMWPE has excellent resistance to chemicals,in addition to the strong oxidizing acid,in a certain temperature and the concentration range of competence of various corrosive medium (acid,alkali,salt) and various organic media.
5. Absorb impact energy
UHMWPE has excellent shock absorption,impact energy absorption value is the highest in all plastic,and it has a excellent effect of the silencer.
6. Low temperature resistance
UHMWPE has excellent low temperature resistance,and can be used as a low temperature component in the nuclear industry because of its still have the ductility at low temperature (-269℃).
7. Hygiene and no toxicity
8. Not easy adhesion
UHMWPE surface adsorption force is very weak, its ability to resist adhesion to the plastic is next only to the best PTFE, so the surface of the product and other materials are not easy to stick.
9. Hydrophobic property
UHMWPE water absorption rate is very low, generally less than 0.01%, only 1% of PA6, and therefore do not need to dry before processing.
10. Tensile strength
As the UHMWPE has the necessary structural characteristics of the super tension orientation, so there is no comparable ultra-high tensile strength, its tensile strength up to 3 - 3.5GPa.
Property Of UHMWPE
|
Propertise |
Unit |
Result |
|
Impact strength |
KJ/m2 |
>140 |
|
Water absorption |
% |
<0.01 |
|
Compressive strength |
Mpa |
30 |
|
Ball indentation hardness |
Mpa |
26-30 |
|
Friction coefficient |
- |
0.07-0.11 |
|
Impact strength(notched) |
MJ/mm2 |
no |
|
Tensile strength |
Kg/cm2 |
300-400 |
|
Hardness Rockwell |
- |
D65 |
The standard size of our uhmwpe plastic sheets
|
Varieties |
Size |
Usage |
|
High wear-resistance |
4300*1300* (1-200) or 6000*2000*(1-300) |
Bin liner, port machinery, mining machinery, |
|
Pure super high plate |
Papermaking, ceramics, transport machinery, food, packaging, environmental protection |
|
|
Anti static panels |
Mine downhole operation, terminal, grain processing and other electrostatic parts |
|
|
Flame retardant board |
Mine downhole operation, mainly used for flammable parts of coal bunker |
|
|
Color plate |
The packaging industry, decoration materials, fender board |
|
|
Double color plate |
Easy to find wear, easy to check |
|
|
Anti ultraviolet |
Open hopper, hopper, wharf fender |
|
|
Micro plate |
Filter plate |
