Computer Control Electronic Universal Testing Machine
Posting date : Oct 13, 2016
Membership
Free Member Scince Oct 13, 2016
Min. Order Quantity
1 set
Supply Abillity
360 set per year
Port
Tianjin
Payment Terms
TT
Package
wooden case
Keyword :
Category
Contact
Lexi
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
HRJ
Model Number
WDW series
HS-CODE
8419-90
Package & Delivery Lead Time
Package
wooden case
Delivery Lead Time
10 working days
Specifications
Type of Certification
CE
Reference no.
JHR864
Name.
CE
Start Date (validity period)
0000-00-00
End Date (validity period)
0000-00-00
Detailed Description
Introduction:

  •  tensile, compression, bending, torsion, shearing testing and researching with variety of metal, nonmetal material and composite material under room temperature.
  •   testing and providing data according standards of GB, ISO, JIS, ASTM, DIN, BS and other international standard.
  • sample of thin plate, panel, belt, foil, flat bar, wire, bar, proximate matter, pipe, sheet, square, round, rectangle, and annulus shaped, cast iron, nonmetal alloy of cast iron, pipe section, proportional and nonproportional, fully wall thickness of longitudinal and horizontal peeling strip, rectangle and round section.
  •  tensile, compression and bending test with varety of material by adding gripper.
  • tensile, compression and bending test with variety of rubber, plastic, film and other nonmetal material
  •   test with variety of metal, thin metal, wire, fine wire, fiber, elastomer, foam.
  •  test with textile, food, medcine, cosmetic, biological material.
  •   tensile, peeling and welding strength test with electronic component.
  •   test with wooden, paper, film production and other nonmetal material.
  • strain relaxation and adhesive strength test.


Important specification

WDW-1kN/2kN/5kN/10kN/20kN/50kN/100kN
 Electronic Universal Testing Machine (Standard type)(CE)
1
Max. test force
5kN/10kN/20kN
30kN/50kN
100kN
2
grade of machine
Gradeof 0.5/ 1
3
measure range of loading
0.4%~100%FS (grade of 0.5) /1%~100%FS (grade of 1)
4
relative error of indicating value
Between ±0.5%(grade 0.5) /±1.0% (grade 1)
5
resolution of force
1/±300000FS (resolution of fully stroke is not changed)
6
measure range of deformation
0.2%~100%
7
adjusting range of speed for force controlled
0.005%~5%FS/S
8
Control precision of speed for force
When speed is <0.05%FS, between ±1% of setting value
When speed is ≥0.05%FS, between ±0.5% of setting value
9
adjusting range of speed for deformation
0.005~5%FS/s
10
precision of speed for deformation
When speed is <0.05%FS/s, between ±1% of setting value
When speed is ≥0.05%FS/s, between ±0.5% of setting value
11
adjustable range of speed for displacement
0.001~600mm/min (customized high speed of system 0.001~2000mm/min)
12
control precision of speed for displace
Between ±0.2% of setting value
13
constant force, deformation, displacement control range
0.5%~100%FS
14
control precision of constant force, deformation, displacement
When speed is ≥10%FS, between ±0.5% of setting value,
When speed is <10%FS,between ±1% of setting value.
15
effective test span
400mm
400mm
500mm
16
moving stroke of transom
1000mm
1000mm
1200mm
17
voltage
~220V±10% 50Hz (reliable landing)
18
Rate of machine
400W
750W
2000W
19
size of loading frame(LWH)
860x460x1750mm
940x520x1850mm
1050x560x2150mm
20
weight
≈300kg
≈500kg
≈800kg
