Multi-function crawler excavator

본문 바로가기


Home > Product > Multi-function crawler excavator
Product
Multi-function crawler excavator
Posting date : Aug 18, 2016
Membership
Free Member Scince Aug 11, 2016
FOB Price
USD35000
Min. Order Quantity
1
Supply Abillity
2000
Port
Shanghai
Payment Terms
TT
Package
02/40HQ
Keyword :
Category
Contact
Jack Chen
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
JG
HS-CODE
8429-
Package & Delivery Lead Time
Package
02/40HQ
Detailed Description
JG-65S Tech specification of wheel excavator:
Range of operation
Boom length 3030mm
Arm length 1860mm
Maximum Digging Reach 6000mm
Maximum Digging Depth 3380mm
Maximum Digging Force 45KN
Maximum Digging Height 5800mm
Maximum Dumoing Height 4300mm
Back-end radius of gyration 1775mm
Dimensions
(Length*width*height)travel position 5500*2100*2850mm
Wheel base 2600mm
Track(Front/rear) 1660mm/1580mm
Ground clearance of counterweight 1060mm
Min ground clearance 200mm
Tech performance and specification
Angle of rotation 360°
Machine weight 6000kg
Engine model 4D35G/498
Rated Power 48KW
Rated Speed 2300r/min
Hydraulic system working pressure 19.5Mpa
Hydranlic system flow 110L/min
Metering gear pump 2*25ml/r
Max Hauling force 45KN
Walking speed 35km/h
Grade Climbing ability 58%/30°
Tyre model 750.16
Volume Of Bucket 0.2-0.3m3
Revolution Overdrive Pressure 16Mpa
Full circle swinging time 5.5s
Fqt Fuel Quantity  ≥4L/h
Capacity Of The Fuel Tank 130L
Hydraulic Tank Capacity  110L
