Range of operation | |
Boom length | 3475-3670mm |
Arm length | 1860mm |
Max radius of capture | 6000mm |
Grab the biggest opening width | 1250~1500mm |
Grab the minimum opening width | 200~300mm |
Maximum RADIUS weight capacity | 0.5~0.6t |
Grapple rotation angle | 360° |
Max dumping height | 4700mm |
Back-end radius of gyration | 1775mm |
Dimensions | |
(Length*width*height)travel position | 6000*2100*2850mm |
Wheel base | 2600mm |
Track(Front/rear) | 1660mm/1580mm |
Ground clearance of counterweight | 1060mm |
Min ground clearance | 200mm |
Tech performance and specification | |
Angle of rotation | 360° |
Machine weight | 7800kg |
Engine model | YN38GB2/4102增压 |
Rated Power | 65kw |
Rated Speed | 2400r/min |
Hydraulic system working pressure | 19.5Mpa |
Hydranlic system flow | 110L/min |
Metering gear pump | 2*25ml/r |
Grapple swing speed | 15~30r/min |
Walking speed | 36km/h |
Grade Climbing ability | 58%/30° |
Tyre model | 825.16 |
Revolution Overdrive Pressure | 16Mpa |
Full circle swinging time | 5.5s |
Fqt Fuel Quantity | ≥4L/h |
Capacity Of The Fuel Tank | 130L |
Hydraulic Tank Capacity | 110L |
