China [CN] Cemented carbide wire drawing dies
1. Description of tungsten carbide wire drawing dies:
Tungsten carbide wire drawing dies
carbide drawing dies
Carbide nibs in blanks
Wire straightening & guide dies
Carbide coating dies
PCD wire drawing dies
UKO is suppling both carbide nibs in blanks and finshed carbide drawing dies with steel case.
2. Application of carbide wire drawing dies:
steel wire rod plant using drawing:
low carbon steel wire
middle carbon steel wire
hight carbide steel wire
stainless steel wire
copper wire
3. Standard size of carbide wire drawing dies
| item No. | case size(mm) | nid size(mm) | hole size | Tolerance | ||
| OD | H | od | h | mm | mm | |
| 1 | 25x12 | 9x6 | 0.15~0.5 | 0~-0.02 | ||
| 2 | 30x16 | 13x10 | 0.5~2.6 | 0~-0.02 | ||
| 3 | 32x23 | 16x13 | 0.8~3.5 | 0~-0.02 | ||
| 4 | 32x23 | 16x14 | 1.0~3.5 | 0~-0.02 | ||
| 5 | 40x25 | 20x17 | 1.5~6.5 | 0~-0.02 | ||
| 6 | 40x26 | 22x18 | 1.8~6.5 | 0~-0.02 | ||
| 7 | 50x28 | 25x20 | 3.0~9.5 | 0~-0.02 | ||
| 8 | 70x35 | 30x22 | 5.5~12.5 | 0~-0.02 | ||
| 9 | 75x35 | 35x25 | 8.5~16.5 | 0~-0.02 | ||
| 10 | 80x35 | 40x25 | 16.5~21.5 | 0~-0.02 | ||
| 11 | 110x45 | 50x28 | 21.5~24.5 | 0~-0.02 | ||
| 12 | 120x50 | 60x35 | 24.5~34.5 | 0~-0.02 | ||
| 13 | 130x60 | 70x35 | 34.5~43.5 | 0~-0.02 | ||
| 14 | 140x60 | 80x35 | 34.5~45.5 | 0~-0.02 | ||
| 15 | 150x60 | 90x35 | 45.5~51 | 0~-0.02 | ||
| 16 | 160x75 | 100x40 | 51~56 | 0~-0.02 | ||
| 17 | 170x75 | 110x40 | 57~65 | 0~-0.02 | ||
| 18 | 180x80 | 120x45 | 66~69 | 0~-0.02 | ||
| 19 | 190x85 | 130x50 | 70~76 |
0~-0.02 |
||
4. Drawing of wire drawing dies
5. Pictures of wire drawing dies
6. Packing and shipping of carbde wire drawing dies
7/ SERVICE OF ZHUZHOU UKO
1. feedback within 24 hours;
2. good english communication;
3. professional suggestion on product;
4. good traning export sales person;
5. skilled in tungsten carbide sell;
6. could issue the C/O(certificate of origin)to customer to reduce the tax;
7. could accept all payment terms of T/T(both in advanced and after shipment), D/P, D/A, L/C, western union, paypal and etc
8. could offer free samples below 0.5kgs under the condition of freight paid by customer;
9.MOQ 5kgs for sintered blank;
High quality & Excellet service & Excellent reputation !
ZHUZHOU UKO CEMTNED CARBIDE CO.,LTD.
-------------------------------------------------------------------------------
Address: Xinhua West Road, Hetang district, Zhuzhou, Hunan, P.R.China .
Postal code: 41200
