Feeltek different colors laser engraving system

Posting date : Aug 15, 2016

Click enlarge Image

Membership

Free Member Scince Aug 11, 2016

FOB Price

USD12000/set

Min. Order Quantity

1 set

Supply Abillity

100 sets/month

Port

Shanghai

Payment Terms

T/T

Package

standard exported wooden case

Keyword :

laser marking system

Products application

The main products of FEELTEK includes 3 axis systems in C serial and F serial,wide field laser marking system , 3D surface &relief engraving system, laser pattern marking on moving walk piece based on visual position system, laser manufacturer by adding and removing material , 3D scanning and overall solution which integrated with lasers.

So , specifically , our product can do the works of die mould making , laser cleaning ,denim laser washing , 3D surface engraving ,LDS , LGP and visual positioning . And many other work of engraving .

F20

Features

Provide metal parts for high-end application

Process 3D forms, planar, inclined and curved surfaces with LenMark-3DS

Variable 3D marking area up to 600 mm x 600 mm x 80 mm

General specifications
Serial		F20pro
X/Y axis Galvanometer		CTI
Z axis Galvanometer		CTI
Control card		CTI
Software suite		Lenmark-3D or Lenmark-3DS (optional)
Power supply		Control card		Environmental requirement
Input Voltage	170~264 VAC	Input interface	XY2-100 Protocol	Ambient temperature	0℃ ~ +40℃
Output Voltage	24 VDC	Output interface	USB	Storage temperature	-10℃ ~ +60℃
Current	10 A	Laser type	Fiber laser	Humidity	≤ 75 % non condensing

Specifications for deflection unit		Specifications for optics
Scan angle (°)	±11.25	Aperture size (mm)	20
Repeatability (urad)	8	Laser	YAG
Max. Gaindrift (ppm/K)	100	Wavelength (nm)	1064
Max. Offsetdrift (urad/K)	30	Coating	AR Coating
Long-term drift over 8h (mrad)	0.5	Specifications for structure
Maximal processing speed (mm/s)	4500 (No deformation)	Weight (Kg)	12
Step response (ms)	≤0.4	Dimension [L×W×H] (mm)	800×125×177

Field size & Spot diameter
Field size (mm)	100×100×20	200×200×40	300×300×60	400×400×60	500×500×60	600×600×80
Spot diameter 1/e2(mm)	0.014	0.022	0.310	0.040	0.049	0.058

Key advantages

Hardware

Unique optical path design based on different lasers, with low optical loss and 20% efficiency increased.Rapid response with high speed THK guide rail of Zaxis.High stability with CTI galvanometer.

Software

Provide application-specific interfaces to production line.Optional 3D engraving software, easily achieve surface marking and 3D relief.

Technical support

Offer complete technical service with self-developed hardware and software.Provide the best spare parts under same price or same configuration.

Customer service

On-site technical training is provided for first-time customer.Off-sitetechnical engineer training is offered for regular customer.

Key advantages

Hardware

Unique optical path design based on laser beam characteristics, low optical loss with 20% efficiency increased.

Rapid response with high speed THK guide rail of Z axis.

High stability with CTI galvanometer.

Software

Provide application-specific interfaces to production line.

Optional 3D engraving software, easily achieve surface marking and 3D relief.

Technical support

Offer complete technical service with self-design hardware and software.

Provide the best spare parts under same price or same configuration.

Customer service

On-site technical training is provided for first-time customer.

Off-site technical engineer training is offered for regular customer.
