Model |
HS-C 1/2 |
HS-C1 |
HS-C1 1/2 |
HS-C2 |
HS-C3 |
HS-C5 |
HS-C10 |
HS-C20 |
|
Capacity ( t ) |
0.5 |
1 |
1.5 |
2 |
3 |
5 |
10 |
20 |
|
Standard lifting height (m) |
2.5 |
2.5 |
2.5 |
2.5 |
3 |
3 |
3 |
3 |
|
Test load ( t ) |
0.75 |
1.5 |
2.25 |
3 |
4.5 |
7.5 |
12.5 |
25 |
|
The distance between two hooks (mm) |
255 |
306 |
368 |
444 |
486 |
616 |
700 |
1000 |
|
(hook to hook) |
|||||||||
Chainpull to lift full load (N) |
221 |
304 |
343 |
314 |
343 |
383 |
392 |
392 |
|
No.of Lifting Chain |
1 |
1 |
1 |
2 |
2 |
2 |
4 |
8 |
|
Diameter of load chain (mm) |
6 |
6 |
8 |
6 |
8 |
10 |
10 |
10 |
|
Dimensions mm |
A |
125 |
147 |
183 |
147 |
183 |
215 |
360.5 |
585 |
B |
111 |
126 |
141 |
126 |
141 |
163 |
163 |
191 |
|
C |
24 |
28 |
34 |
34 |
38 |
48 |
64 |
82 |
|
D |
134 |
154 |
192 |
154 |
192 |
225 |
224 |
224 |
|
Net weight (kg) |
8 |
10 |
12 |
14 |
24 |
36 |
63 |
156 |
|
Gross weight (kg) |
10 |
13 |
16 |
17 |
28 |
45 |
68 |
194 |
|
Packing Dimension (cm) |
28* 21* 17 |
30* 24* 18 |
33* 25 *19 |
34* 29 *20 |
38* 30* 20 |
45* 35* 24 |
62* 50* 28 |
70* 46* 75 |
