Double Screw Extruder for Puff Snacks

INTRODUCTION:

1. Description:Twin screw extruder adopts corn, rice, wheat, oat, barley etc as ingredients to make puffs snack. Through friction of screw and barrel, the grains are cooked in the extruder. Forming is at the die face cutter. The product shape is determined by a combination of the die aperture, including ball, tube, stick, ring, fruit loop, star, wheel and flower etc.

2. Raw materials: adopts corn, rice, wheat, oat, barley etc as ingredients

3. Products: Variety shapes are available for ball, tube, stick, ring, fruit loop, star, wheel and  flower and heart shape by adjusting the mould in the extruder.

4. Capacity: 150kg/h, 240kg/h, 500kg/h

5. Power Consumption: 27kw

Features of Our Twin Screw Extruder:

a. Screw with 38CrMoAL excellent material. The HRC hardness is around 60---62.The screws are made by alloy steel and special craft, the screw life is longer. And it has good self-cleaning ability and does not need to discharge or clean the barrel and screw, when roasting or replacing of materials.

b.The extrusion barrel is constructed of carbon steel, is made by #45 steel, stainless steel coating.

c.The gearbox has automatic lubrication function, with extends gear life.

d.Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.

e. Main Motor from SIEMENS(CHINA), ensure its Powerful Extrusion and Excellent Performance.

The advantages of twin screw extrusion:

Twin screw extrusion has become the standard over time in several industries because it offers numerous advantages over single screw extrusion:

·         More consistency in production and control of product quality

·         Increased productivity due to continuous processing, faster start up and shut down between                     product changes, quick changeover and advanced automation

·         Greater flexibility, with the capability to process a wide range of raw materials

·         Optimized footprint thanks to energy and water savings

·         Simple and easy to maintain and clean
