High Capacity Water Bottle / Lubricant oil filling machine SUS304 2000 - 18000bph Quick Detail: 1. Control: PLC2. driver: ELEC3. material: SUS3044. Productivity: 2000-18000bph Description: Automatic 2 in 1 bottle oil filler machine is suitable to fill and seal 500ml-5Lit oil bottles,cans of cooking oil,mustard oil,sunflower oil,refined oil,vegitable oil etc.Online filler with cap sealing unitEdible Oil Filling also suitable to fill 15Kg Mustard Oil Tins as optional choice Applications: Automatic 2 in 1 bottle oil filler machine is most commonly applicable for pharmaceutics, daily chemicals, foodstuffs, cosmetics, pesticides and other industrials.Typical application: Mineral Water, Cooking Oils, Juice, Detergent,Sauce, Salad, Butter & Margarine, Ketchup, Jams, Cream, Honey, shampoos etc. Specifications:
Model |
Number of washing filling and capping |
Production capacityBottle per hour(0.5L) |
Applicable bottle specifications (mm) |
Power(kw) |
Dimension(mm) |
GZS12/5 |
12, 5 |
2000-3000 |
0.25L-2L50-108 mmH=170-340mm |
3.58 |
2100x1400x2300 |
GZS16/6 |
16, 5 |
4000-5000 |
3.58 |
2460x1720x2350 |
|
GZS18/6 |
18, 6 |
6000-7000 |
4.68 |
2800x2100x2350 |
|
GZS24/8 |
24, 8 |
9000-10000 |
4.68 |
2900x2500x2350 |
|
GZS32/10 |
32, 10 |
12000-14000 |
6.58 |
3100x2800x2350 |
|
GZS40/12 |
40,12 |
15000-18000 |
6.58 |
3500x3100x2350 |
Competitive Advantage: 1. Scientific and reasonable design of the machine, beautiful appearance, easy operation and maintenance.2. The handle of the machine can be freely and conveniently turned to adjust so that various types of bottles can be used.3. All parts contacted with oil product are made of SS304 and have no process blind angles to enable easy cleaning.
