Quick Detail:
1. Usage: shrink label on bottles(PVC,PET,OPS)2. High efficiency and accuracy.3. Flexible for different bottle size4. PLC Control
Description:
According to the characteristics of label , we make improvement from the aspects of mechanical structure, circuit design, and intellectual control to improve the production efficiency. It can satisfy the demands of various beverage manufacturers as well as reduce the production cost for the clients and improve the production rate.
H type design of the mechanism ensures the requirements of four-wheel drive, automatic centering and four-wheel balanced pressure. Because of the design of the equal velocity ratio, it completely realizes the goals of accurate , smooth label transmission, stable operation and swift label cutting.
The labeling machine with a breakthrough of the traditional technology of casting sleeve label, the equipment can integrate three to four trapping label machine varieties into one. It only needs to change the modules to realize the casting label of different varieties and types.
Applications:
Wide use range: food, beverage, medicine industry, for PET bottle, glass bottle, and other PVC, PE material bottle,sleeve shrink labels.
Specifications:
Input Power |
1.5KW |
Input Voltage |
3 Phase, 380/220VAC |
Production Efficiency |
6000-10000b/h |
Size of Host Machine(mm) |
2100L*850W*2000H |
Applicable Diameter of Bottle Body |
dia.28mm-125mm |
Applicable Length of Label |
30 mm~250mm |
Applicable Thickness of Label |
0.03 mm~0.13 mm |
Applicable Internal Diameter of Paper Tube |
5″~10″adjust it at will |
Competitive Advantage:
1. Frame by SS 304, and imported magnalium alloy material.
2. Hi accuracy labeling applicator with good design cutting system.
3. Special synchronous knife structure, special designed knife seat, high efficiency and accuracy.
