China [CN] Introduction of Best Price and Excellent Quality Ball Mill Hot sale
The ball mill is a key machine that smashes the materials having been crushed, and is widely used in industries like cement, silicate products, new 52555 building materials, refractory materials, fertilizer, black and non-ferrous metal ore dressing and glass ceramics production. Ball grinding mill or ball grinder can realize both dry and wet grindings for different ores and other grindable materials.
Ball mill is suitable for grinding all kinds of ores and other materials, so it is widely used in mineral dressing, building materials and chemical industries. There are dry type and wet type grinding ways. According to the different ore discharging ways, ball mills can be divided into grid and overflow types.
Features of Best Price and Excellent Quality Ball Mill Hot sale
Fote ball mill machine and various types and all models, including cement ball mill, tube type ball mill, cone ball mill, ceramics ball mill, overflow ball mill, grid ball mill, energy-saving ball mill, etc. Fote fully meets the diverse needs of users with various models.
.jpg)
Structure of Best Price and Excellent Quality Ball Mill Hot sale
A ball mill is made up of six parts: feeding device, discharging device, rotary part, transmission parts (including reducer, small transmission gear, electric engine and electronic control). The main frame of the ball mill is a cylinder inside which there set a wear resisting lining plate, bearing cylinder and the rotary shaft, driving parts like electric engine, transmission gear, belt wheel and triangle belt etc. The ball mill runs smoothly and steadily with reliable performance.
.jpg)
Working principle of Best Price and Excellent Quality Ball Mill Hot sale
This energy saving ball mill is a horizontal cylindrical grid-shaped rotating device with the outer gear transmission, two positions. Materials pass through the feeding device into the first bin of the mill spirally and regularly via the hollow shaft. The first bin has ladder plate or corrugated plate inside which has installed steel balls with different specifications. The cylinder rotates and produces centrifugal force to raise the steel balls up and then to fall from a certain height, thus generating the force to impact and grind the materials. After the coarse grinding in the first bin, the materials enter into the second bin via the single deck bulkhead. This bin covered with a flat liner plate with steel balls inside will do further grinding of the materials. Powdery materials are discharged through the unloading grate board. This is the whole grinding procedure of ball grinder or grinding ball.
Fote is a famous ball mill machine manufacturer and China ball mill supplier. There are many ball mills for sale. The dry and wet ball mill price is reasonable and the quality is quite great. Welcome to pay a visit to get more detailed information.
Parameter
| Model | Shell rotation speed (r/min) | Ball load(t) | Feeding size (mm) | Discharging size (mm) | Capacity(t/h) | Motor power (kw) | Total weight(t) |
| Φ 900×1800 | 36-38 | 1.5 | ≤20 | 0.075-0.89 | 0.65-2 | 18.5 | 5.5 |
| Φ 900×3000 | 36 | 2.7 | ≤20 | 0.075-0.89 | 1.1-3.5 | 22 | 6.7 |
| Φ 1200×2400 | 36 | 3 | ≤25 | 0.075-0.6 | 1.5-4.8 | 30 | 12 |
| Φ 1200×3000 | 36 | 3.5 | ≤25 | 0.074-0.4 | 1.6-5 | 37 | 12.8 |
| Φ 1200×4500 | 32.4 | 5 | ≤25 | 0.074-0.4 | 1.6-5.8 | 55 | 13.8 |
| Φ 1500×3000 | 29.7 | 7.5 | ≤25 | 0.074-0.4 | 2-5 | 75 | 16.8 |
| Φ 1500×4500 | 27 | 11 | ≤25 | 0.074-0.4 | 3-6 | 110 | 21 |
| Φ 1500×5700 | 28 | 12 | ≤25 | 0.074-0.4 | 3.5-6 | 130 | 25.8 |
| Φ 1830×3000 | 25.4 | 11 | ≤25 | 0.074-0.4 | 4-10 | 130 | 29 |
| Φ 1830×4500 | 25.4 | 15 | ≤25 | 0.074-0.4 | 4.5-12 | 155 | 35.5 |
| Φ 1830×6400 | 24.1 | 21 | ≤25 | 0.074-0.4 | 6.5-15 | 210 | 43 |
| Φ 1830×7000 | 24.1 | 23 | ≤25 | 0.074-0.4 | 7.5-17 | 245 | 43.8 |
| Φ 2100×3000 | 23.7 | 15 | ≤25 | 0.074-0.4 | 6.5-36 | 155 | 34.8 |
| Φ 2100×4500 | 23.7 | 24 | ≤25 | 0.074-0.4 | 8-43 | 245 | 42 |
| Φ 2100×7000 | 23.7 | 26 | ≤25 | 0.074-0.4 | 8-48 | 280 | 56.6 |
| Φ 2200×4500 | 21.5 | 27 | ≤25 | 0.074-0.4 | 9-45 | 280 | 51.8 |
| Φ 2200×6500 | 21.7 | 35 | ≤25 | 0.074-0.4 | 14-26 | 380 | 60 |
| Φ 2200×7000 | 21.7 | 35 | ≤25 | 0.074-0.4 | 15-28 | 380 | 62 |
| Φ 2200×7500 | 21.7 | 35 | ≤25 | 0.074-0.4 | 15-30 | 380 | 64.8 |
| Φ 2400×3000 | 21 | 23 | ≤25 | 0.074-0.4 | 7-50 | 245 | 58 |
| Φ 2400×4500 | 21 | 30 | ≤25 | 0.074-0.4 | 8.5-60 | 320 | 69 |
| Φ 2700×4000 | 20.7 | 40 | ≤25 | 0.074-0.4 | 12-80 | 380 | 94 |
| Φ 2700×4500 | 20.7 | 48 | ≤25 | 0.074-0.4 | 12-90 | 480 | 102 |
| Φ 3200×4500 | 18 | 65 | ≤25 | 0.074-0.4 | As per process conditions | 630 | 137 |
| Φ 3600×4500 | 17 | 90 | ≤25 | 0.074-0.4 | As per process conditions | 850 | 158 |
| Φ 3600×6000 | 17 | 110 | ≤25 | 0.074-0.4 | As per process conditions | 1250 | 175 |
| Φ 3600×8500 | 18 | 131 | ≤25 | 0.074-0.4 | 45.8-256 | 1800 | 252 |
| Φ 4000×5000 | 16.9 | 121 | ≤25 | 0.074-0.4 | 45-208 | 1500 | 203 |
| Φ 4000×6000 | 16.9 | 146 | ≤25 | 0.074-0.4 | 65-248 | 1600 | 218 |
| Φ 4000×6700 | 16.9 | 149 | ≤25 | 0.074-0.4 | 45-252 | 1800 | 238 |
| Φ 4500×6400 | 15.6 | 172 | ≤25 | 0.074-0.4 | 54-306 | 2000 | 280 |
| Φ 5030×6400 | 14.4 | 216 | ≤25 | 0.074-0.4 | 68-386 | 2500 | 320 |
| Φ 5030×8300 | 14.4 | 266 | ≤25 | 0.074-0.4 | 88-500 | 3300 | 403 |
| Φ 5500×8500 | 13.8 | 338 | ≤25 | 0.074-0.4 | 108-615 | 4500 | 525 |
After-sales Service:
Fotecompany has reliable products and experienced service team.We believe you not only need the machines, but also good after sales service. Based on the technology and quality, we would provide a gratified,save worry and disburden service for you we can fully satisfy your demands and have a large customer base. Our products sell well in _Morocco,_Iran, Kazakhstan, Uzbekistan,Kyrghyzstan, Russia, India, Indonesia, Thailand, Philippines, Korea, Yemen, Kenya, Mongolia, Nigeria, Vietnam_. Except our own products, we provide OEM services and accept customized order as well.
FAQ
1.How is the quality of your products?
Our products are manufactured strictly according to national and international standard, and we take a test on every grinder before delivery.
Guaranteed:
If products` quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.
2.How about price?
Yes, we are factory and be able to give you the lowest price than market one, and we have a policy that " for saving time and absolutely honest business attitude,we quote as low as possible for any customer, and discount can be given according to quantity".
Thanks for your reading and more product information can be shared with you by further communication !
