Enduring colorful
|
high weatherability engineering resin as the surface material ofthe tile. In in the natural environment, product possesses exceptional durability, under exposing to ultravioletlight, moisture, high and low temperature conditions, 28 years of the stability of color can be promised. Δ E ≤5
|
Thermal and sound insulation
|
coefficient of thermal conductivity is 0.293 w/m.k, about a third of clay tile, onefifth of 10 mm thick cement, one over two thousand of the color 0.5 mm steel. Phoneme determined throughexperiments show that, under heavy rain, hail, gale, such as the weather, PVC roof tile still can absorb well
|
Waterproof
|
select high weatherability resin, density and no water absorption, no waterseepage problems of micro porous, big size area, less roof seam, contact closely. Thus it has excellentwaterproof performance, can save the waterproof layer.
|
Fireproof
|
PVC roof tile’s main body material is PVC resin. Its chemical properties of materialsdetermines its flame retardant properties, fire prevention performance achieve B1 level.
|
Light weight
|
belongs to the light structure material, can effectivelyreduce the load of the building, enhance security, and at the same time it can save construction main bodymaterial, convenient carrying, lifting, reduce construction cost.
|
Insulation
|
PVC roof tile is non-conductive and intact when accidental discharge.
|
Volume stability
|
Expansion coefficient of PVC roof tile is 4.93 x 10-5 (1/5 ℃), it possesses low expansion andthe bidirectional tensile properties, even the temperature change is very huge, it also can ensure thethe samegeometric size.
|
Impact resistance
|
Another basic characteristic of impact resistance is not easy be broken by the natural force, because ofadopt high weather resistance resin with high impact resistance. The fall test shows that no crack by 1 kg ofsteel ball fall free from 3 m high, no broken with10 shock performance under low temperature.
|
Self-cleaning
|
PVC roof tile is not easy absorb dust itself. It looks clean as new after the rains washed out,no fouling washed.
|
Corrosion-resistant
|
PVC roof tile can resist acid and alkali, salt and other chemical corrosion. No chemical reactionunder the experiment for alkali, salt, and less than sixty percent of the various kinds of acid for 24 hours .
|
Environmental protection and energy saving
|
PVC roof tile achieve assessment by development science and technology center ofnational ministry of construction department. Product environmental protection, energy saving and renewableuse, is popularized to support new product "environmental protection, energy saving" at present.
|
Product width
|
840mm, 900mm, 1130mm, 1200mm, 1300mm
|
Product thickness
|
1.5-3mm
|
Extruder type
|
80/156 & 50/30
|
Output capacity
|
390
|
Length of machine
|
26m
|
No.
|
Machine
|
Qty.
|
|
1
|
Screw loader for extruder
|
1set
|
Main tile extrusion line
Ridge tile forming
|
2
|
SJZ80/156 conical twin-screw extruder(PVC)
|
1set
|
|
3
|
Vacuum loader and drying hopper
|
1set
|
|
4
|
SJ50/30 single screw extruder(ASA)
|
1set
|
|
5
|
Extrusion mould and distributor
|
1set
|
|
6
|
Calibration mould and trimming device
|
1set
|
|
7
|
Haul off unit
|
1set
|
|
8
|
Cutter
|
1set
|
|
9
|
Stacker
|
1set
|
|
10
|
Ridge tile Oven
|
1set
|
|
11
|
Ridge tile Forming machine
|
1set
|
|
|
|
|
|
12
|
Screw loader for SRL-Z300/600 Mixer
|
1set
|
Auxiliary equipment
|
13
|
SRL-Z300/600 Mixer unit
|
1set
|
|
14
|
PC400 Crusher
|
1set
|
|
15
|
SMP400 Pulverizer
|
1set
|
