bucket chain dredger made in China for sale
China [CN] The bucket chain gold dredger use the buckets, driven by guide wheels on continuous rotation on the bucket bridge, so the bucket could dredge mud and sand to the water above, then into the separating system, solids larger than 10 mm will go into the tail-box, tailing discharged to place far away from gold dredger. Less than 10 mm of material from the flow channel into the Gold Sands separation system, based on the difference between the relative density of sand and gold, gold will fall into the bottom since of the high density,sand and other material will float on the surface,and discharged to the tail system by water.
The gold separating equipment attached with the bucket gold dredger is decided by the detail condition of the mine,such as the type and shape of the gold;the percentage of the material smaller than 5mm etc. Every customer may have different request according to their own situation,and we can offer customized service,site investigation and testing are also available.
|
SPECIFICATIONS FOR BUCKET CHAIN GOLD DREDGER
|
|||
|
Product Model
|
JLBGD-50
|
JLBGD-100
|
JLBGD-150
|
|
Dredging Depth
|
5m
|
10m
|
15m
|
|
Capacity
|
50 m3/h
|
100 m3/h
|
150 m3/h
|
|
Length
|
18m
|
26m
|
33m
|
|
Front Width
|
2.2m
|
2.4m
|
2.4m
|
|
Rear Width
|
1.8m
|
1.8m
|
2.2m
|
|
Height
|
0.9m
|
0.9m
|
1.05m
|
|
Bucket Volume
|
0.06m3
|
0.06m3
|
0.09m3
|
|
Bucket Quantity
|
54
|
68
|
76
|
1) Simple structure,dismantle pontoons,enough space within 2 pontoons,more stable and easy to disassemble;
2) Bucket type to dredge material from the river,improve the capacity and concentrate;
3) Customized sieving trommel according to the detail size of the material,good efficiency;
4) Gold separating system is equipped according to special condition;
5) Tail discharge system,easy and low cost,and also protect the dredger to continuous work.
* Inquiry and consulting support.
* View our Factory anytime.
* Inspection before delivery.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
If you need to know more about the product,you can send inquiry to us,and it's appreciated if you could offer more condition about your mining site,that will help to choose most suitable model.
We can also go to you site to investigation for you if you need,or we can help test your ore samples.
Click enlarge Image
