DQF1-3B model One way normally open non return valve dc 3v 6v pneumatic actuator valve multifunctional exhaust valve electric
0 likes
China [CN] DQF1-3B model One way normally open non return valve dc 3v 6v pneumatic actuator valve multifunctional exhaust valve electric
| Rated Voltage | DC3.0V | DC6.0V | |
| Rated Current | <110mA | <100mA | |
| Pressure | 0-350mmHg | ||
| Air Releasing Speed | <3S(Connected to a 100CC container,pressure falling from -280mmHg to 15mmHg) | ||
| Air Leakage | <3mmHg/min.(Connected to a 100CC container,pressurize from 0 to -280±10mmHg,stop and hold 30S,the dropped pressure meassured in one minute) | ||
| Media | Air | ||
| Life test | >200,000 cycles(Connected to a 100CC container,ON 10S,OFF 5S as a cycle) | ||
| Working temperature | 5℃ ~55℃ | ||
| Net Weight | 11g | ||
| Application | Mainly applied for mini blood pressure monitor,physiotherapy massage,medical,healthcare and household products | ||
DIMENSION:
Click enlarge Image
