PSE802G 30W standard IEEE802 3At single port injector
0 likes
China [CN] PSE802G
IEEE 802.3at compliant
The maximum transmission power is 25.4w
Poe transmission power supply distance up to 100m
Automatic detection and identification of power receiving equipment and automatic matching of output power
Built in power supply, plug and play, no management required
Pse802g single port Gigabit Ethernet power supply equipment, The power supply is suitable for indoor use (please put a waterproof box outdoors. It can work normally at the input voltage of 100vac ~ 240VAC. The power supply is connected with the network terminal equipment through category 5 cables. It has an Ethernet data port and an output port after data and power synthesis. The equipment can be one-way Ethernet equipment, such as router, switch, wireless AP, network telephone and industrial network terminal , network camera, etc. shall be provided in accordance with IEEE802 The POE power supply application of 3af / at international standard meets the requirements of providing efficient engineering in places where it is impossible to provide power remotely or where Ethernet network cable power supply mode is adopted to improve system reliability and simplify equipment installation. At the same time, it can also be used with POE separator (such as ps5712, poe5912, etc.) to provide stable power supply and data transmission for non Poe equipment.
Click enlarge Image
