GPS PPK Kit for DJI UAV with Professional Survey Software
0 likes
China [CN]
what is GPS PPK Kit?
GPS PPK Kit is an indispensable accessory for a drone for aerial surveying and mapping work.
No need for communication technology support, just record static data.
Plane accuracy reached10mm+1pmm，height accuracy reached 20mm+2pmm
Boarder survey rage and less possibale to lose satellite signals.
Because of these features, it is widely used in terrain surveys that require a large number of settings or difficult to set GCPs(ground control points).
And also applied in power inspection,traffic law enforcement,plant protect mapping,aerial surveying＆mapping,city management and so on...
Size 56.4*45.3*14.6mm
Weight 56g
Operating T -20 ~+65℃
Battery capacity 4.2V 1500mAh
Antenna voltage 3.3V
Length of work 12h
Storage 16GB
Record format RINEX,NMEA
Output format NMEA,LLH/XYZ
Update rate 5 Hz
Signal GPS/QZSS L1,L2
GLONASS G1
BeiDou B1
Galileo E1
SBAS
channels 184
More details contact at
Click enlarge Image
